Richelieu WEBKIT1234772 HAWA-Junior Z Series Sliding Door SystemRichelieu WEBKIT1234772 HAWA-Junior Z Series Straight Sliding Door System is designed for both commercial and premium residential applications, accommodating wood doors weighing up to 100 kg. This standard straight-sliding system features a surface top-mount two-way suspension plate, ensuring stability and ease of use. The integrated track stopper includes an adjustable retaining device that effectively resists door bounce back, enhancing safety and functionality. For an even smoother operation, consider the optional SoftMove closing system. This versatile system supports various track options, including basic anodized, ceiling mount for clip-on fascia, and wall mount for clip-on fascia, allowing for single sliding, bi-parting, and bypassing configurations. Ideal for use in closets, pocket doors, and as standard access doors, the HAWA-Junior Z Series provides flexible installation and premium performance. The system accommodates door heights up to 10 feet and door thicknesses ranging from 1 3/16 to 3 5/32 inches, with widths between 40 1/2 and 49 1/4 inches. The anodized aluminum finish ensures durability, while the upper roller position and soft-close features guarantee quiet operation. For accurate installation, remember to cut a groove of 12 mm x 20 mm at the bottom of the door for the guiding system.
HAWA-Junior Z Series Straight Sliding Door System
The HAWA-Junior Z Series, featuring the HAWA-Junior 40/Z, Junior 80/Z, and Junior 100/Z is a standard straight-sliding system for wood doors weighing up to 100 kg.
Features:
- Surface top-mount two-way suspension plate
- Integrated track stopper with adjustable retaining device to resist door bounce back
- SoftMove closing system (sold separately)
- Versatile track options for single sliding, bi parting, and bypassing applications
- Select from the following tracks:
a) Basic anodized track
b) Ceiling mount track for clip-on fascia
c) Wall mount track for clip-on fascia
- Smooth and quiet premium performance trolleys
- Flexible door installation
The HAWA-Junior Z Series is an ideal solution for commercial and premium residential projects. For use with doors between rooms, premium closets, and pocket doors.
IMPORTANT: Use metric dimensions for greater accuracy during installation. Cut a groove 12 mm x 20 mm at the bottom of the door for bottom guide.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Standard Access Door, Pocket Door
Brand: Junior
Brand Model: Hawa Junior
Detailed Door Movement: Single Sliding
Door Height: Max. 3 050 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: Min. 30 mm
Door Width: Max. 1 250 mm
Finish: Anodized Aluminum
Function: Sliding Door
Groove Needed for Guiding System: Yes
Length - Overall Dimensions: 98 3/8 in*
Load Capacity: 90.4 to 176 lb*
Manufacturing Material: Aluminum
Number of Doors: 1
Overall Length: 2 500 mm
Product #: WEBKIT1234772
Product number: WEBKIT1234772
Product №: WEBKIT1234772
Roller Position: Upper
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Stopper: Two
Track Length: 2 500 mm
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 80 kg
