Richelieu WEBKIT1236393 HAWA APERTO 60H Modular Sliding Door SystemRichelieu WEBKIT1236393 HAWA APERTO 60H Modular Sliding Door System offers a versatile solution for creating movable wall partitions in both commercial and residential settings. Designed to accommodate a maximum panel weight of 132 lb (60 kg) per door, this system features anodized tracks that can be either surface or recessed mounted, ensuring seamless integration into various architectural designs. The HAWA APERTO 60H Modular can support up to nine door panels with a standard modular parking unit. Its innovative center stop includes an adjustable retention spring, allowing sliding doors to remain stationary while easily operating the pivot door. The tracks are designed for easy extension and joining using connecting pins and fixing plates, ensuring unobstructed door movement. Additionally, the system includes parking modules featuring a servicing track end piece for hassle-free trolley loading. With options for bottom guides, keyed and non-keyed deadbolts, and even optional curved track segments, the flexibility of this sliding door system makes it ideal for multifunctional spaces like meeting rooms, restaurants, and great rooms. The system accommodates door heights of up to 8 ft 6 in and a thickness range of 1 3/8 to 1 31/932 in, making it a reliable choice for various design needs. Technical support is readily available for pre-calculating parking areas, ensuring a smooth installation process.
HAWA APERTO 60H Modular Sliding Door System
The HAWA APERTO 60H Modular is a movable wall partition system for sliding and stacking doors.
Features:
- Maximum panel weight of 132 lb (60 kg) each
- All tracks and guide channels are plain anodized
- Tracks can be surface and recessed mount
- Standard modular parking unit for up to nine door panels
- Center stop with adjustable retention spring to keep sliding doors stationary so that the pivot door can be operated
- Tracks are joined and extended with connecting pins and fixing plates without obstructing movement of the doors
- Parking modules include servicing track end piece for trolleys to load easily
- Optional curved track segments available for changes in direction, via special order
- Offers modular units with and without bottom guides
- Locking options keyed and non-keyed deadbolts
- Technical support available via email to pre-calculate parking areas:
Canada:
[email protected] USA:
[email protected] The HAWA APERTO 60H Modular 90 Degree is an ideal solution for multifunctional rooms in commercial and residential environments, such as meeting rooms, restaurants, storage areas, and other great rooms.
Attributes
Ship via: No UPS - Common Carrier Only
Bottom Guide: Yes
Brand: Hawa
Detailed Door Movement: Stacking
Door Configurations: Perpendicular (90 degree) to upper track
Door Height: 2 600 mm
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 35 to 50 mm
Door Width: 550 to 950 mm
Function: Pivot and Sliding Doors
Load Capacity: 132 lb*
Number of Doors: 4
Product #: WEBKIT1236393
Product number: WEBKIT1236393
Product №: WEBKIT1236393
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Ceiling Mount
Weight Capacity per Door: 60 kg
