Richelieu WEBKIT1236394 HAWA APERTO 60H Modular Sliding Door SystemRichelieu WEBKIT1236394 HAWA APERTO 60H Modular Sliding Door System offers a versatile solution for creating movable wall partitions, ideal for both commercial and residential spaces. This system supports sliding and stacking doors with a maximum panel weight capacity of 132 lb (60 kg) each, ensuring robust functionality. Designed with flexibility in mind, the HAWA APERTO 60H features anodized tracks that can be surface or recessed mounted, allowing for seamless integration into various environments. The standard modular parking unit accommodates up to nine door panels, while the center stop includes an adjustable retention spring, keeping sliding doors stationary for easy pivot door operation. Installation is straightforward, as tracks can be connected and extended with pins and fixing plates without hindering door movement. Optional curved track segments are also available for unique directional changes. The system supports door configurations perpendicular to the upper track, with dimensions allowing for door heights of 8 ft 6 in and widths ranging from 21 5/8 to 37 3/8 in, making it suitable for multifunctional rooms such as meeting areas and restaurants. With technical support available for pre-calculating parking areas, the HAWA APERTO 60H Modular is the perfect choice for enhancing space efficiency and aesthetic appeal.
HAWA APERTO 60H Modular Sliding Door System
The HAWA APERTO 60H Modular is a movable wall partition system for sliding and stacking doors.
Features:
- Maximum panel weight of 132 lb (60 kg) each
- All tracks and guide channels are plain anodized
- Tracks can be surface and recessed mount
- Standard modular parking unit for up to nine door panels
- Center stop with adjustable retention spring to keep sliding doors stationary so that the pivot door can be operated
- Tracks are joined and extended with connecting pins and fixing plates without obstructing movement of the doors
- Parking modules include servicing track end piece for trolleys to load easily
- Optional curved track segments available for changes in direction, via special order
- Offers modular units with and without bottom guides
- Locking options keyed and non-keyed deadbolts
- Technical support available via email to pre-calculate parking areas:
Canada:
[email protected] USA:
[email protected] The HAWA APERTO 60H Modular 90 Degree is an ideal solution for multifunctional rooms in commercial and residential environments, such as meeting rooms, restaurants, storage areas, and other great rooms.
Attributes
Ship via: No UPS - Common Carrier Only
Bottom Guide: No
Brand: Hawa
Detailed Door Movement: Stacking
Door Configurations: Perpendicular (90 degree) to upper track
Door Height: 2 600 mm
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 35 to 50 mm
Door Width: 550 to 950 mm
Function: Pivot and Sliding Doors
Load Capacity: 132 lb*
Number of Doors: 4
Product #: WEBKIT1236394
Product number: WEBKIT1236394
Product №: WEBKIT1236394
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Ceiling Mount
Weight Capacity per Door: 60 kg
