Richelieu WEBKIT1236453 HAWA-Junior A Series Straight Sliding Door SystemRichelieu WEBKIT1236453 HAWA-Junior A Series Straight Sliding Door System offers a robust solution for both commercial and premium residential projects. Designed to accommodate wood doors weighing between 264 lb and 550 lb (120 kg to 250 kg), this system is versatile enough for various applications, including wall partitions and pocket doors. Key features include a surface top mount galvanized suspension plate and integrated track stoppers, allowing for an adjustable retaining device that effectively minimizes door bounce back. The system supports multiple configurations, including single sliding, biparting, and bypassing, catering to diverse design needs. Premium performance trolleys ensure smooth and quiet operation, enhancing user experience. The HAWA-Junior A Series also offers an optional SoftMove 120 soft-close mechanism for doors up to 264 lb (120 kg), providing added safety and convenience. With a maximum door height of 11 ft 11 in, a thickness ranging from 1 9/16 to 3 5/32 in, and a width of 36 to 59 in, it accommodates a variety of door sizes. The system is ceiling-mounted and features upper roller positioning, making installation straightforward while maintaining a clean aesthetic. Experience the perfect blend of functionality and elegance with this expertly engineered sliding door system.
HAWA-Junior A Series Straight Sliding Door System
The HAWA-Junior A Series are standard straight sliding systems for wood doors weighing from 264 lb to 550 lb (120 kg to 250 kg) each.
Features:
- Series: Junior 120/A, 160/A, and 250/A
- Surface top mount galvanized suspension plate
- Integrated track stoppers with adjustable retaining device to resist door bounce back
- Versatile track options for single sliding, biparting, and bypassing applications
- Premium performance trolleys that are smooth and quiet
- Available SoftMove 120 soft-close mechanism for doors weighing 264 lb (120 kg)
The HAWA-Junior A Series is an ideal solution for commercial and premium residential projects, wall partitions, and pocket doors.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Sliding Wall
Brand: Junior
Brand Model: Hawa Junior
Detailed Door Movement: Biparting
Door Height: Max. 3 650 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 0 to 40 mm
Door Width: Max. 3 000 mm
Groove Needed for Guiding System: Yes
Length - Overall Dimensions: 19 ft 8 in*
Load Capacity: 353 lb*
Number of Doors: 2
Overall Length: 6 m
Product #: WEBKIT1236453
Product number: WEBKIT1236453
Product №: WEBKIT1236453
Roller Position: Upper
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Stopper: Two
Track Length: 6 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: 160 kg
