Richelieu WEBKIT1236456 HAWA JUNIOR B Series Sliding Door System InstructionsRichelieu WEBKIT1236456 HAWA JUNIOR B Series Sliding Door System offers a sophisticated solution for both commercial and residential applications, accommodating door weights from 88 lb to 550 lb (40 kg to 250 kg). This system features a low-profile rebate/mortise mount suspension plate that blends seamlessly at the top of the door, minimizing gaps without the need for a fascia. Engineered for versatility, the HAWA JUNIOR B Series includes adjustable track options available in various lengths, suitable for single sliding, biparting, and bypassing applications. Its integrated track stopper, complete with an adjustable retaining device, effectively prevents door bounce back, ensuring a smooth and quiet operation. The high-quality trolleys contribute to the system's premium performance and durability. Designed for doors ranging in height from 70 7/8 to 157 inches, with thickness between 1 3/8 to 1 31/932 inches, this system is perfect for room dividers, pocket doors, and wall partitions. The satin aluminum finish adds a modern touch. For those seeking added convenience, the SoftMove soft/self-closing mechanism is available separately for doors weighing between 88 lb to 264 lb (40 kg to 120 kg), enhancing functionality further. The HAWA JUNIOR B Series is truly a remarkable choice for any space.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Standard Access Door
Brand: Hawa
Detailed Door Movement: Single Sliding
Door Height: Max. 3 050 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: 35 to 50 mm
Door Width: 1 030 to 1 275 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 98 3/8 in*
Load Capacity: 90.4 to 176 lb*
Number of Doors: 1
Overall Length: 2.5 m
Product #: WEBKIT1236456
Product number: WEBKIT1236456
Product №: WEBKIT1236456
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 2.5 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 80 kg
