Richelieu WEBKIT1236458 HAWA JUNIOR B Series Sliding Door SystemRichelieu WEBKIT1236458 HAWA JUNIOR B Series Sliding Door System offers a sophisticated solution for sliding wood doors, accommodating weights from 88 lb to 550 lb (40 kg to 250 kg) per door. Designed with a low-profile rebate/mortise mount suspension plate, this system allows for minimal gaps between the door and upper track, eliminating the need for fascia. The integrated track stopper features an adjustable retaining device to effectively resist door bounce-back, ensuring a smooth and reliable operation. With versatile track options available in various lengths, the system supports single sliding, biparting, and bypassing applications, making it suitable for diverse project requirements. Designed for both commercial and residential settings, the HAWA JUNIOR B Series is ideal for room dividers, pocket doors, wall partitions, and low headroom scenarios. The premium trolleys provide a smooth, quiet performance, contributing to a refined aesthetic. For added convenience, a SoftMove soft/self-closing mechanism can be purchased separately for doors weighing between 88 lb to 264 lb (40 kg to 120 kg). This top-hung system, finished in satin aluminum, accommodates door heights from 70 7/8 in to 157 in and door widths ranging from 27 1/8 in to 40 3/8 in, making it a versatile choice for modern spaces.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Standard Access Door
Brand: Hawa
Detailed Door Movement: Biparting
Door Height: Max. 3 050 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: 35 to 50 mm
Door Width: 690 to 1 025 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 13 ft 1 in*
Load Capacity: 90.4 to 176 lb*
Number of Doors: 2
Overall Length: 4 m
Product #: WEBKIT1236458
Product number: WEBKIT1236458
Product №: WEBKIT1236458
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 4 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 80 kg
