Richelieu WEBKIT1236459 HAWA JUNIOR B Series Sliding Door SystemRichelieu WEBKIT1236459 HAWA JUNIOR B Series Sliding Door System seamlessly combines functionality with modern design, making it an exceptional choice for both commercial and residential projects. Designed to accommodate wood doors weighing between 88 lb to 550 lb (40 kg to 250 kg), this system features a low-profile rebate/mortise mount suspension plate that ensures minimal gap between the door and the upper track, eliminating the need for a fascia. The integrated track stopper includes an adjustable retaining device to effectively resist door bounce back, enhancing safety and usability. With versatile track options available in various lengths, the system supports single sliding, biparting, and bypassing applications, offering flexibility for different spaces. Experience smooth and quiet operation thanks to the premium performance of the long-lasting trolleys. The HAWA JUNIOR B Series also offers an optional SoftMove soft/self-closing mechanism for doors weighing from 88 lb to 264 lb (40 kg to 120 kg), ensuring a gentle and controlled closure. Ideal for room dividers, pocket doors, and wall partitions, this top-hung system accommodates door heights from 70 7/8 to 157 inches and thicknesses between 1 3/8 to 1 31/32 inches. Its elegant satin aluminum finish adds a touch of sophistication to any interior setting.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Standard Access Door
Brand: Hawa
Detailed Door Movement: Biparting
Door Height: Max. 3 050 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: 35 to 50 mm
Door Width: 1 030 to 1 500 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 19 ft 8 in*
Load Capacity: 90.4 to 176 lb*
Number of Doors: 2
Overall Length: 6 m
Product #: WEBKIT1236459
Product number: WEBKIT1236459
Product №: WEBKIT1236459
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 6 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 80 kg
