Richelieu WEBKIT1236460 HAWA JUNIOR B Series Sliding Door SystemRichelieu WEBKIT1236460 HAWA JUNIOR B Series Sliding Door System offers a sophisticated solution for both commercial and residential applications, accommodating wood doors weighing between 88 lb and 550 lb (40 kg to 250 kg). This system is designed with a low-profile rebate/mortise mount suspension plate, allowing for minimal gaps between the door and the upper track, eliminating the need for a fascia. Featuring an integrated track stopper, this system includes an adjustable retaining device to effectively resist door bounce back, ensuring a smooth and stable operation. The versatile track options cater to various configurations, including single sliding, biparting, and bypassing applications, all while delivering premium performance with long-lasting trolleys. The HAWA JUNIOR B Series also offers optional SoftMove mechanisms for doors weighing from 88 lb to 264 lb (40 kg to 120 kg), enhancing user experience with soft closing capabilities. Designed for door heights from 70 7/8 to 157 inches and thicknesses of 1 1/2 to 2 1/4 inches, this system supports two doors with an overall length of 19 ft 8 in. Ideal for room dividers, pocket doors, and low headroom applications, the satin aluminum finish complements any environment while maintaining functionality.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Sliding Wall / Standard Access Door
Brand: Hawa
Detailed Door Movement: Biparting
Door Height: Max. 3 050 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: 38 to 57 mm
Door Width: 1 150 to 1 525 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 19 ft 8 in*
Load Capacity: 223 to 265 lb*
Number of Doors: 2
Overall Length: 6 m
Product #: WEBKIT1236460
Product number: WEBKIT1236460
Product №: WEBKIT1236460
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 6 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 120 kg
