Richelieu WEBKIT1236461 HAWA JUNIOR B Series Sliding Door SystemRichelieu WEBKIT1236461 HAWA JUNIOR B Series Sliding Door System offers a robust and elegant solution for sliding wood doors weighing between 88 lb and 550 lb (40 kg to 250 kg). Designed for both commercial and residential applications, this system features a low-profile rebate/mortise mount suspension plate that ensures minimal gaps between the door and upper track, eliminating the need for a fascia. The integrated track stopper includes an adjustable retaining device to prevent door bounce back, ensuring smooth and reliable operation. With versatile track options available in various lengths, the HAWA JUNIOR B Series accommodates single sliding, biparting, and bypassing applications with ease. This system is engineered for premium performance, featuring long-lasting trolleys that operate quietly. The system supports doors with heights ranging from 78 3/4 to 157 inches, thicknesses from 1 1/2 to 2 1/4 inches, and widths from 36 to 78 3/4 inches. The satin aluminum finish adds a modern touch to any setting. For added convenience, a SoftMove soft/self-closing mechanism is available separately for doors weighing up to 264 lb (120 kg). Ideal for room dividers, pocket doors, and wall partitions, the HAWA JUNIOR B Series offers an exceptional balance of style and functionality.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Sliding Wall / Standard Access Door
Brand: Hawa
Detailed Door Movement: Single Sliding
Door Height: Max. 3 660 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: 38 to 57 mm
Door Width: Max. 2 000 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 13 ft 1 in*
Load Capacity: 267 to 353 lb*
Number of Doors: 1
Overall Length: 4 m
Product #: WEBKIT1236461
Product number: WEBKIT1236461
Product №: WEBKIT1236461
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: None
Soft- Closing: No
Track Finish: Satin Aluminum
Track Length: 4 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 160 kg
