Richelieu WEBKIT1236468 HAWA JUNIOR B Series Sliding Door SystemRichelieu WEBKIT1236468 HAWA JUNIOR B Series Sliding Door System is designed to accommodate wood doors weighing between 88 lb to 550 lb (40 kg to 250 kg), making it an excellent choice for various residential and commercial applications. This system features a low-profile rebate/mortise mount suspension plate, allowing for a minimal gap between the top of the door and the upper track, eliminating the need for a fascia. Equipped with an integrated track stopper and adjustable retaining device, it effectively reduces door bounce back, ensuring smooth and quiet operation. The system offers versatile track options in multiple lengths suitable for single sliding, biparting, and bypassing configurations. For those seeking enhanced functionality, the optional SoftMove mechanism is available for doors weighing up to 264 lb (120 kg). The HAWA JUNIOR B Series is perfect for creating room dividers, pocket doors, and low headroom applications, with a door height range of 59 to 118 inches and a thickness between 1 3/16 to 1 25/32 inches. Finished in satin aluminum, this system combines durability with aesthetic appeal, making it a valuable addition to any project where quality and performance matter.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Closet and Walk-In Closet
Brand: Hawa
Detailed Door Movement: Bypassing
Door Height: Max. 3 000 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: 30 to 45 mm
Door Width: 550 to 1 050 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 78 3/4 in*
Load Capacity: 44.1 to 88.2 lb*
Number of Doors: 2
Overall Length: 2 m
Product #: WEBKIT1236468
Product number: WEBKIT1236468
Product №: WEBKIT1236468
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 2 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 40 kg
