Richelieu WEBKIT1240095 CS Door Collection System GuideRichelieu WEBKIT1240095 CS Door Collection System is expertly crafted for those seeking a reliable solution for sliding telescopic doors. Accommodating multiple parallel wood doors, this system supports impressive load capacities of up to 200 lb (90 kg) for each door and up to 500 lb (227 kg) collectively, making it suitable for both residential and commercial applications. Available in two- and three-door hardware set packs, the system features one-piece track options designed for door thicknesses of 1 3/8 in (35 mm) and 1 3/4 in (45 mm). The innovative bottom guide brackets link the doors, eliminating the need for floor guide channels. Standard vertical "pick-up" aluminum profiles, measuring 92 in (2336 mm) tall, ensure a seamless transition between doors, while the option to cut profiles to size allows for customization. Ideal for room dividers, large closets, storage units, and multifunctional spaces, the system is versatile in its applications. Additional features include adjustable door movement with a biparting and telescoping design, upper-positioned ball bearing rollers, and the flexibility of surface or recessed track mounting. Elevate your space with the Richelieu WEBKIT1240095, a smart choice for modern design and functionality.
CS Door Collection System
The Cavity Sliders CS Door Collection System is designed for sliding telescopic doors and for stacking multiple parallel wood doors weighing up to 200 lb (90 kg) and 500 lb (227 kg) each.
Features:
- Available in two- and three-door hardware set packs
- One-piece track options for double and triple spaced doors with a 1 3/8 in (35 mm) and 1 3/4 in (45 mm) thickness
- Bottom guide brackets link doors so that floor guide channels are not necessary
- Vertical "pick-up" aluminum profiles are standard 92 in (2336 mm) tall and ensure a secure and stable link between doors for a smooth transition from one door the next. The profiles can be cut to size.
- Recessed floor guide channels and guide are available for extra wide doors
Ideal for residential and commercial applications for small and large room dividers, multiple door closets and storage units, meeting rooms, multifunctional rooms, and open space planning.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Screen Panel
Brand: Cavity Sliders
Detailed Door Movement: Bypassing / Telescoping
Displayed in These Showrooms: Ottawa
Door Height: 126 in
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding / Movable Wall
Door Thickness: 1 3/4 in
Door Width: 30 to 38 in
Function: Sliding Door
Length - Overall Dimensions: 96 in
Load Capacity: 200 lb
Manufacturing Material: Aluminum
Number of Doors: 2
Overall Length: 96 in
Product #: WEBKIT1240095
Product number: WEBKIT1240095
Product №: WEBKIT1240095
Roller Position: Upper
Roller Type: Ball Bearing
Running Track Fixing: Surface and Recessed
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Track Length: 96 in
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Track Type: Box Track
Track type: Box Track
Weight Capacity per Door: 200 lb
