Richelieu WEBKIT1240099 CS Door Collection System GuideRichelieu WEBKIT1240099 CS Door Collection System offers an innovative solution for sliding telescopic doors, accommodating multiple parallel wood doors with impressive load capacities of up to 200 lb (90 kg) and 500 lb (227 kg) each. This system is available in two- and three-door hardware set packs, providing flexibility for various configurations. Designed for seamless operation, the one-piece track options cater to double and triple spaced doors with thicknesses of 1 3/8 in (35 mm) and 1 3/4 in (45 mm). The bottom guide brackets connect doors, eliminating the need for floor guide channels, while the vertical "pick-up" aluminum profiles, standard at 92 in (2336 mm) tall, create a secure link for a smooth transition between doors. These profiles can be easily cut to size for custom installations. Suitable for both residential and commercial applications, the CS Door Collection is ideal for small and large room dividers, multiple door closets, meeting rooms, and open space planning. With an adjustable design, a door height of 126 in, and a width range of 22 to 52 in, this top-hung system is a versatile choice for modern spaces. Experience the blend of functionality and style that Richelieu products deliver.
CS Door Collection System
The Cavity Sliders CS Door Collection System is designed for sliding telescopic doors and for stacking multiple parallel wood doors weighing up to 200 lb (90 kg) and 500 lb (227 kg) each.
Features:
- Available in two- and three-door hardware set packs
- One-piece track options for double and triple spaced doors with a 1 3/8 in (35 mm) and 1 3/4 in (45 mm) thickness
- Bottom guide brackets link doors so that floor guide channels are not necessary
- Vertical "pick-up" aluminum profiles are standard 92 in (2336 mm) tall and ensure a secure and stable link between doors for a smooth transition from one door the next. The profiles can be cut to size.
- Recessed floor guide channels and guide are available for extra wide doors
Ideal for residential and commercial applications for small and large room dividers, multiple door closets and storage units, meeting rooms, multifunctional rooms, and open space planning.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Screen Panel
Brand: Cavity Sliders
Detailed Door Movement: Biparting / Telescoping
Displayed in These Showrooms: Ottawa
Door Height: 126 in
Door Installation: Top Hung
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 1 3/4 in
Door Width: 38 to 52 in
Function: Sliding Door
Length - Overall Dimensions: 288 in
Load Capacity: 500 lb
Manufacturing Material: Aluminum
Number of Doors: 4
Overall Length: 288 in
Product #: WEBKIT1240099
Product number: WEBKIT1240099
Product №: WEBKIT1240099
Roller Position: Upper
Roller Type: Ball Bearing
Running Track Fixing: Surface and Recessed
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Track Length: 288 in
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Track Type: Box Track
Track type: Box Track
Weight Capacity per Door: 500 lb
