Richelieu WEBKIT1240111 CS Ceiling Mount Track System GuideRichelieu WEBKIT1240111 CS Ceiling Mount Track System is designed for standard sliding wood doors, offering a robust solution with a load capacity of up to 500 lb (227 kg) per door. This system caters to various applications, making it ideal for residential, commercial, and institutional projects. It accommodates doors ranging from 36 to 48 inches in width and 1 3/8 to 1 3/4 inches in thickness, ensuring versatility in design. The hardware sets are available without soft-close mechanisms for doors weighing up to 200 lb (90 kg) and 500 lb (227 kg). For those seeking enhanced functionality, options with SofStop soft-close mechanisms are available, supporting single or twin action for lighter doors. The innovative CarriSnap suspension plate allows for easy mounting and release of the upper trolley without requiring tools, streamlining the installation process. Featuring large wheel trolleys with precision ground bearings, the track system ensures smooth operation. The contemporary style and clear anodized aluminum finish blend seamlessly into any environment. Recessed floor guide channels are also available for extra-wide doors, providing stability and ease of use. Elevate your space with the Richelieu CS Ceiling Mount Track System, where durability meets style.
CS Ceiling Mount Track System
The Cavity Sliders CS Ceiling Mount Track Systems are for standard sliding wood doors weighing up to 500 lb (227 kg) each.
Features:
- Hardware sets without soft-close mechanisms for doors weighing up to 200 lb (90 kg) and 500 lb (227 kg)
- Hardware sets with SofStop soft-close mechanisms choices are single or twin action for doors weighing up to 176 lb (80 kg) or single action for doors up to 264 lb (120 kg) each
- CarriSnap mounting suspension plate for the top of the door for mounting and releasing the upper trolley without tools
- Track sets for doors 1 3/8 in (35 mm) to 1 3/4 in (45 mm) thick
- Clip-on fascia available in silver (clear) and bronze anodized finish
- Recessed floor guide channels and guide are available for extra wide doors
- Large wheel trolleys with precision ground bearings for smooth running
Ideal for residential, commercial, and institutional projects for a wide variety of applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Standard Access Door
Brand: Cavity Sliders
Detailed Door Movement: Single Sliding
Door Height: 120 in
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 1 3/8 to 1 3/4 in
Door Width: 36 to 48 in
Finish: Clear Anodized Aluminum
Function: Sliding Door
Length - Overall Dimensions: 96 in
Load Capacity: 500 lb
Manufacturing Material: Aluminum
Number of Doors: 1
Overall Length: 96 in
Product #: WEBKIT1240111
Product number: WEBKIT1240111
Product №: WEBKIT1240111
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Style: Contemporary
Track Length: 96 in
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Track Type: Box Track
Track type: Box Track
Weight Capacity per Door: 500 lb
