Richelieu WEBKIT1242718 CS Barn Door Sliding Door SystemRichelieu WEBKIT1242718 CS BARNDOOR Sliding Door System offers an exceptional solution for both residential and commercial settings, accommodating heavy wood doors with a remarkable weight capacity of up to 400 lb (180 kg) without SoftStop, or 264 lb (120 kg) with the optional SoftStop feature. This system is designed for door thicknesses ranging from 1 1/4 in (32 mm) to 1 3/4 in (45 mm), allowing versatility in various applications. Constructed with a sleek aluminum black anodized finish, this commercial-grade system ensures both durability and aesthetic appeal. The anti-jump system provides peace of mind, preventing wheels from coming off the track. With adjustable fixing brackets, it accommodates different door projections, including narrow and wide tracks for projections between 1 5/8 in (40 mm) and 3 1/8 in (80 mm). Available in multiple lengths-72 in (1828 mm), 84 in (2134 mm), 96 in (2438 mm), and 120 in (3048 mm)-the CS BARNDOOR system is ideal for large feature doors, access doors, room dividers, and office doors. Whether you're enhancing a modern interior or creating functional spaces, this sliding door system combines smooth operation with robust performance, making it a reliable choice for any project.
CS BARNDOOR Sliding Door System
The CS BARNDOOR Sliding Door system is designed for heavy wood doors, with a weight capacity of 400 lb (180 kg) without SoftStop, or 264 lb (120 kg) with SoftStop (sold separately).
Features:
- Aluminum black anodized finish
- For door thickness of 1 1/4 in (32 mm) to 1 3/4 in (45 mm)
- Anti-jump system ensures wheels cannot jump off the track
- Adjustable fixing bracket for different door projections
- Type NARROW track for door projections 1 5/8 in (40 mm) to 2 3/8 in (61 mm)
- Type WIDE track for door projections 2 3/8 in (62 mm) to 3 1/8 in (80 mm)
- Available in different lengths: 72 in (1828 mm), 84 in (2134 mm), 96 in (2438 mm), 120 in (3048 mm)
- Commercial grade system
- Smooth operating
Ideal solution for residential and commercial applications for large heavy feature doors, access doors, room dividers, and office doors.
Other track lengths are possible by special order. Contact your local sales office and technical team for more information.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Standard Access Door, Barn Door
Detailed Door Movement: Single sliding, Barn door
Door Height: Max. 120 in
Door Material: Wood
Door Movement: Straight Sliding
Door Projection: 2 3/8 to 3 1/8 in
Door Thickness: 1 1/4 to 1 3/4 in
Door Width: 24 to 48 in
Function: Sliding Door
Length - Overall Dimensions: 96 in
Load Capacity: 400 lb
Number of Doors: 1
Overall Length: 96 in
Product #: WEBKIT1242718
Product number: WEBKIT1242718
Product №: WEBKIT1242718
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Track Mounting: Wall Mount
Weight Capacity per Door: 400 lb
