Richelieu WEBKIT1242935 SCORRI FLAT 10 Sliding Door System, 10 kg Panel CapacityRichelieu WEBKIT1242935 SCORRI FLAT 10 Sliding Door System offers a versatile solution for both residential and commercial spaces. Designed specifically for cabinet and closet doors, this system supports a weight capacity of up to 10 kg (22 lb), making it ideal for various applications such as pantries, wardrobes, and furniture. The top hung running sliding system facilitates inset applications, ensuring a sleek and modern aesthetic. It features a rear surface mount suspension plate equipped with a height adjustment cam for precise installation. Compatible with wood doors ranging from 5/8 in (16 mm) to 3/4 in (20 mm) thick, the SCORRI FLAT 10 guarantees smooth operation with concealed track stoppers and an anti-lift pin for enhanced security. Installation is straightforward and flexible, with options for single and double surface mount tracks that can be mounted side by side for triple bypass applications. The system maintains a clean look while providing reliable functionality. For optimal results, ensure to follow the installation guidelines, including cutting a groove and drilling as specified. The silver finish adds a contemporary touch, making this sliding door system a perfect fit for any stylish interior. Whether you are enhancing a closet or creating a functional storage solution, Richelieu’s SCORRI FLAT 10 is designed to meet your needs with ease and elegance.
SCORRI FLAT 10 Sliding Door System - Weight Capacity per Panel 10 kg
The SCORRI FLAT 10 sliding door system is designed for cabinet and closet doors for three different weight capacities: 22 lb (10 kg), 66 lb (30 kg), and 110 lb (50 kg).
Features:
- Top hung running sliding system for inset applications
- Rear surface mount suspension plate with height adjustment cam
- Hardware for wood doors 5/8 in (16 mm) to 3/4 in (20 mm) thick
- Concealed track stoppers with retaining device
- Anti-lift pin for secure installation
- Choose from a selection of single and double surface mount tracks
- Single and double tracks can be mounted side by side for triple bypassing applications
- Simple and flexible installation
- Smooth operation
IMPORTANT: Use metric dimensions for greater accuracy during installation. Cut a groove 10 mm by 9 mm at the bottom of the door for bottom guide. Drill without going through a 20 mm diameter by 10 mm deep hole similar to a European style concealed hinge, offset as per the instructions.
Ideal solution for residential and commercial applications for pantries, furniture, bookshelves, wardrobes, armoires, closets, walk-in closets, and storage.
Attributes
Application: Closet and Walk-In Closet, Pantry, Furniture, Cabinet, Storage
Detailed Door Movement: Single sliding
Displayed in These Showrooms: Toronto, Mississauga
Door Height: 1 219 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inset/Inlay
Door Thickness: 16 to 20 mm
Door Width: 300 to 1 000 mm
Drilling: 20 mm
Drilling Depth: 10 mm
Finish: Silver
Height Clearance: 35 mm
Length - Overall Dimensions: 78 3/4 in*
Load Capacity: 22 lb*
Number of Doors: 1
Overall Length: 2 000 mm
Product #: WEBKIT1242935
Product number: WEBKIT1242935
Product №: WEBKIT1242935
Roller Position: Upper
Roller Type: Axle (Bushing)
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Stopper: Two
Track Finish: Silver
Track Mounting: Ceiling Mount
Track type: C-Shape
Weight Capacity per Panel: 10 kg
