Richelieu WEBKIT1242938 SCORRI FLAT 30 Sliding Door System, 66 lb Capacity per PanelRichelieu WEBKIT1242938 SCORRI FLAT 30 Sliding Door System offers a sophisticated solution for cabinet and closet doors, accommodating panels weighing up to 66 lb (30 kg). Designed for inset applications, this top-hung sliding system ensures both functionality and elegance in any space. The system features a rear surface mount suspension plate that includes a height adjustment cam for easy installation. It supports wood doors ranging from 5/8 in (16 mm) to 3/4 in (20 mm) thick, allowing for versatile applications in residential and commercial settings such as pantries, wardrobes, and walk-in closets. With concealed track stoppers and an anti-lift pin, your doors will glide smoothly and securely. Installation is simple and flexible, with options for single or double surface mount tracks, which can be mounted side by side for triple bypassing configurations. The roller type is ball bearing, ensuring effortless movement, while the C-shaped track provides a sleek finish. For optimal results, precise measurements are crucial; be sure to use metric dimensions during installation. The system's finish in silver enhances its modern appeal, making it a perfect addition to any contemporary design project. Transform your storage areas with Richelieu's commitment to quality and innovative design.
SCORRI FLAT 30 Sliding Door System - Weight Capacity per Panel 66 lb (30 kg)
The SCORRI FLAT 30 sliding door system is designed for cabinet and closet doors with a weight capacity of 66 lb (30 kg).
Features:
- Top-hung running sliding system for inset applications
- Rear surface mount suspension plate with height adjustment cam
- Hardware for wood doors 5/8 in (16 mm) to 3/4 in (20 mm) thick
- Concealed track stoppers with a retaining device
- Anti-lift pin for secure installation
- Choice of single and double surface mount tracks
- Single and double tracks can be mounted side by side for triple bypassing applications
- Simple and flexible installation
- Smooth operation
IMPORTANT: Use metric dimensions for greater accuracy during installation. Cut a groove 10 mm by 9 mm at the bottom of the door for the bottom guide. Drill without going through a 20 mm diameter by 10 mm deep hole, similar to a European-style concealed hinge, offset as per the instructions.
An ideal solution for residential and commercial applications, for use with pantries, furniture, bookshelves, wardrobes, armoires, closets, walk-in closets, and storage areas.
Attributes
Application: Closet and Walk-In Closet, Pantry, Furniture, Cabinet, Storage
Detailed Door Movement: Bypassing
Displayed in These Showrooms: Toronto, Mississauga
Door Height: 2 000 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inset/Inlay
Door Thickness: 16 to 20 mm
Door Width: 400 to 1 025 mm
Drilling: 20 mm
Drilling Depth: 10 mm
Finish: Silver
Height Clearance: 35 mm
Length - Overall Dimensions: 78 3/4 in*
Load Capacity: 66.1 lb*
Number of Doors: 2
Overall Length: 2 000 mm
Product #: WEBKIT1242938
Product number: WEBKIT1242938
Product №: WEBKIT1242938
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Stopper: Two
Track Finish: Silver
Track Mounting: Ceiling Mount
Track type: C-Shape
Weight Capacity per Panel: 30 kg
