Richelieu WEBKIT1242942 SCORRI FLAT 50 Sliding Door System - 50 kg Panel CapacityRichelieu WEBKIT1242942 SCORRI FLAT 50 Sliding Door System offers a robust solution for cabinet and closet doors with a weight capacity of 110 lb (50 kg). This top-hung sliding system is specifically designed for inset applications, ensuring a seamless integration into your cabinetry. The rear surface mount suspension plate features a height adjustment cam, allowing for precise alignment and a perfect fit. This system accommodates wood doors ranging from 5/8 in (16 mm) to 3/4 in (20 mm) thick, making it versatile for various projects. The concealed track stoppers are equipped with a retaining device, while the anti-lift pin ensures secure installation. Choose from a selection of single and double surface mount tracks, which can also be configured for triple bypassing applications, enhancing functionality and space efficiency. Installation is straightforward, supported by essential guidelines like using metric measurements for accuracy. Ideal for residential and commercial use, the SCORRI FLAT 50 is perfect for pantries, wardrobes, armoires, and storage areas. With its smooth operation and durable construction, this sliding door system is a reliable choice for those seeking both style and practicality in their spaces.
SCORRI FLAT 50 Sliding Door System - Weight Capacity per Panel 50 kg
The SCORRI FLAT 50 sliding door system is designed for cabinet and closet doors with a weight capacity of 110 lb (50 kg).
Features:
- Top-hung running sliding system for inset applications
- Rear surface mount suspension plate with height adjustment cam
- Hardware for wood doors 5/8 in (16 mm) to 3/4 in (20 mm) thick
- Concealed track stoppers with a retaining device
- Anti-lift pin for secure installation
- Choose from a selection of single and double surface mount tracks
- Single and double tracks can be mounted side by side for triple bypassing applications
- Simple and flexible installation
- Smooth operation
IMPORTANT: Use metric dimensions for greater accuracy during installation. Cut a groove 10 mm by 9 mm at the bottom of the door for the bottom guide. Drill without going through a 20 mm diameter by 10 mm deep hole, similar to a European-style concealed hinge, offset as per the instructions.
Ideal solution for residential and commercial applications, for use with pantries, furniture, bookshelves, wardrobes, armoires, closets, walk-in closets, and storage areas.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Pantry, Furniture, Cabinet, Storage
Detailed Door Movement: Bypassing
Displayed in These Showrooms: Toronto, Mississauga
Door Height: 2 500 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inset/Inlay
Door Thickness: 16 to 20 mm
Door Width: 400 to 1 050 mm
Drilling: 20 mm
Drilling Depth: 10 mm
Finish: Silver
Height Clearance: 35 mm
Length - Overall Dimensions: 9 ft 10 in*
Load Capacity: 110 lb*
Number of Doors: 3
Overall Length: 3 000 mm
Product #: WEBKIT1242942
Product number: WEBKIT1242942
Product №: WEBKIT1242942
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Stopper: Two
Track Finish: Silver
Track Mounting: Ceiling Mount
Track type: C-Shape
Weight Capacity per Panel: 50 kg
