Richelieu WEBKIT1242957 CINETTO PS40.2 Coplanar Sliding SystemRichelieu WEBKIT1242957 CINETTO PS40.2 Coplanar Sliding System offers a versatile solution for large cabinet doors, accommodating weights of up to 132 lb (60 kg) each. This system is designed to handle one, two, or three wood doors, making it an excellent choice for various applications, including closets, pantries, and wardrobes in both residential and commercial settings. Featuring adjustable surface mount hardware, the Cinetto PS40.2 ensures ease of installation and flexibility. It includes a soft-close mechanism for a smooth and quiet operation, enhancing user experience. Notably, there is no special cabinet fabrication required, streamlining your project from the outset. Available in two stylish track finishes-silver and stainless steel effect anodized aluminum-the system complements a wide range of design aesthetics. It supports door heights of up to 9 ft 10 in and accommodates door widths from 35 to 48 1/4 in, with a thickness range of 3/4 to 1 9/16 in. The overall length of the system is 96 1/2 in, with a height clearance of 5 5/32 in. For optimal performance, it is recommended to use a door straightener or stiffener to enhance door rigidity. Upgrade your space with the Richelieu Cinetto PS40.2, where functionality meets design excellence.
CINETTO PS40.2 Coplanar Sliding System
Cinetto PS40.2 Coplanar Sliding System for large cabinet doors weighing up to 132 lb (60 kg) each.
Features:
- Flexible system for one, two, or three wood doors
- Surface mount hardware, adjustable
- Soft-close mechanism included
- No special cabinet fabrication is required
- Two types of track finishes: silver and stainless steel effect anodized aluminum
This is an ideal solution for closets, pantries, large storage millwork, and wardrobes/armoires in residential and commercial applications.
IMPORTANT: We recommend that you use a door straightener/stiffener to make the door more rigid.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Wardrobe, Pantry, Cabinet, Storage
Brand: CINETTO
Brand Model: Cinetto PS40
Detailed Door Movement: Bypassing
Door Height: 3 000 mm
Door Material: Wood
Door Movement: Coplanar
Door Position: Full Overlay, Inset/Inlay
Door Thickness: Min. 19 mm
Door Thickness Including the Handle: 16 to 55 mm
Door Width: 888 to 1 225 mm
Finish: Satin Aluminum
Height Clearance: 131 mm
Length - Overall Dimensions: 96 1/2 in*
Load Capacity: 99.2 to 220 lb*
Manufacturing Material: Aluminum
Number of Doors: 1
Opening: Towards the left
Overall Length: 2 450 mm
PS40 Opening: Towards the left
Product #: WEBKIT1242957
Product number: WEBKIT1242957
Product №: WEBKIT1242957
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Material: Anodized Aluminum
Weight Capacity per Door: 45 to 100 kg
