Richelieu WEBKIT1242958 CINETTO PS40.2 Coplanar Sliding SystemRichelieu WEBKIT1242958 CINETTO PS40.2 Coplanar Sliding System is designed for large cabinet doors, accommodating weights of up to 132 lb (60 kg) each. This versatile system can support one, two, or three wood doors, making it an excellent choice for various applications including closets, pantries, and wardrobes in both residential and commercial settings. Featuring adjustable surface mount hardware, the Cinetto PS40.2 ensures a seamless installation process without the need for special cabinet fabrication. The system includes a soft-close mechanism, providing a quiet and gentle closing action that enhances user experience. Two attractive track finishes are available: silver and stainless steel effect anodized aluminum, allowing for a customized look that complements any decor. This coplanar sliding system is designed for door heights of up to 9 ft 10 in, with a thickness range between 3/4 to 1 9/16 in, and width options from 35 to 48 1/4 in. It utilizes upper-positioned ball-bearing rollers for smooth operation and supports a load capacity between 99.2 to 220 lb, depending on configuration. For optimal performance, it is recommended to use a door straightener or stiffener to enhance door rigidity.
CINETTO PS40.2 Coplanar Sliding System
Cinetto PS40.2 Coplanar Sliding System for large cabinet doors weighing up to 132 lb (60 kg) each.
Features:
- Flexible system for one, two, or three wood doors
- Surface mount hardware, adjustable
- Soft-close mechanism included
- No special cabinet fabrication is required
- Two types of track finishes: silver and stainless steel effect anodized aluminum
This is an ideal solution for closets, pantries, large storage millwork, and wardrobes/armoires in residential and commercial applications.
IMPORTANT: We recommend that you use a door straightener/stiffener to make the door more rigid.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Wardrobe, Pantry, Cabinet, Storage
Brand: CINETTO
Brand Model: Cinetto PS40
Detailed Door Movement: Bypassing
Door Height: 3 000 mm
Door Material: Wood
Door Movement: Coplanar
Door Position: Full Overlay, Inset/Inlay
Door Thickness: Min. 19 mm
Door Thickness Including the Handle: 16 to 55 mm
Door Width: 888 to 1 225 mm
Finish: Satin Aluminum
Height Clearance: 131 mm
Length - Overall Dimensions: 96 1/2 in*
Load Capacity: 99.2 to 220 lb*
Manufacturing Material: Aluminum
Number of Doors: 1
Opening: Towards the right
Overall Length: 2 450 mm
PS40 Opening: Towards the right
Product #: WEBKIT1242958
Product number: WEBKIT1242958
Product №: WEBKIT1242958
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Material: Anodized Aluminum
Weight Capacity per Door: 45 to 100 kg
