Richelieu WEBKIT1243368 HAWA Junior Pocket Door SystemRichelieu WEBKIT1243368 HAWA Junior Pocket Door System offers a robust solution for both commercial and premium residential applications. This top-hung system is designed to accommodate wood doors weighing up to 120 kg, ensuring smooth and quiet operation. The user-friendly installation is facilitated by a surface-mount suspension plate, while the integrated track stopper features an adjustable retaining device designed to prevent door bounce back. The system includes a removable upper track that allows for sophisticated installations, complete with a guide rail insert that promotes seamless door movement. A floor-mounted guide with a flex feature effectively absorbs vibrations, enhancing durability and performance. Compatible with heavy-duty SoftMove closing mechanisms (sold separately), this system is versatile enough for various door thicknesses ranging from 1 3/8 to 1 25/32 inches and widths from 27 1/8 to 37 3/8 inches. For optimal installation, it is essential to use metric dimensions and prepare a groove of 12 mm x 20 mm at the bottom of the door. Note that a cavity for the pocket door must be built by the contractor, as the frame is not included. Experience the blend of functionality and style with Richelieu's HAWA Junior Pocket Door System, perfect for concealed access between rooms and premium closets.
HAWA Junior Z A Pocket Door System
HAWA Junior Z & A Pocket Door System with removable upper track for wood doors weighing up to 120 kg each.
Features:
- Top-hung surface-mount suspension plate for simple installation
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Removeable clip on upper cover molding allows it to be opened for sophisticated installations
- Guide rail insert for bottom of door for smooth operation
- Floor-mounted guide with flex feature to absorb vibrations
- Durable heavy-duty SoftMove closing mechanism available (sold separately)
- Versatile two-part track can be mounted or removed after the pocket door cavity is built
- Smooth and quiet premium performance trolleys
- Flexible door installation
An ideal solution for commercial and premium residential projects, doors between rooms, premium closets, and pocket doors.
IMPORTANT: Use metric dimensions for greater accuracy during installation. Cut a groove 12 mm x 20 mm at the bottom of the door for bottom guide.
Contractor must build cavity for pocket door (frame not included).
Attributes
Application: Standard Access Door, Pocket Door
Brand: Junior 80/100, Junior 120
Brand Model: Hawa Junior 80/100, Hawa Junior 120
Detailed Door Movement: Pocket door
Door Installation: Top Hung
Door Material: Wood
Door Movement: Pocket Door
Door Position: Pocket Door
Door Thickness: 35 to 45 mm
Door Width: 690 to 950 mm
Groove Depth: 20 mm
Groove Needed for Guiding System: Yes
Groove Width at the Bottom of Door: 12 mm
Length - Overall Dimensions: 74 3/4 in*
Load Capacity: 90.4 to 176 lb*
Manufacturing Material: Aluminum
Number of Doors: 1
Overall Length: 1 900 mm
Product #: WEBKIT1243368
Product №: WEBKIT1243368
Roller Position: Upper
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: Yes, Sold Separately
Track Material: Anodized Aluminum
Track Mounting: Pocket Door
Track type: Two part removeable
Weight Capacity per Door: 41 to 80 kg
