Richelieu WEBKIT1243403 Terno Eclectica 50 FluidRichelieu WEBKIT1243403 TERNO ECLETTICA 50 FLUID is a versatile standard straight sliding door system designed for wood doors weighing up to 50 kg. This system features an automatic clip-on suspension bracket that allows for quick, toolless door installation, making it highly convenient for both professionals and homeowners alike. Offering a choice of hardware types, this series includes options such as one soft close mechanism paired with a shock absorber, or two soft close mechanisms for enhanced functionality. It is ADA and Barrier-Free compliant, requiring a low pull force of just 2.1 kg or less, ensuring accessibility. The system supports various mounting options, including ceiling mount and wall mount, and includes clip-on anodized aluminum fascia options suitable for 35 mm or 45 mm thick doors. The TERNO ECLETTICA 50 FLUID series is ideal for high-volume residential and commercial projects, providing seamless access between rooms. A groove is required at the bottom of the door for proper guiding, with an optional two-part floor guide available separately for those wishing to avoid cutting. Designed with adjustable features, this system accommodates door heights from 70 7/8 to 118 inches, and door widths from 29 1/8 to 49 1/4 inches.
TERNO ECLETTICA 50 FLUID
The TERNO ECLETTICA 50 FLUID Series is a standard straight-sliding door system for wood doors weighing up to 50 kg (110 lbs).
Features:
- Automatic clip-on suspension bracket for quick, toolless door installation
- 2 soft close mechanisms
- ADA/Barrier-Free compliant with a low pull force of 2.1 kg or less
- Track options for ceiling mount and wall mount
- Clip-on anodized aluminum fascia options for 35 mm or 45 mm thick doors
- Optional clips for wood fascia supplied by the contractor
The TERNO ECLETTICA 50 FLUID Series is an ideal solution for access doors between rooms for high-volume residential and commercial projects.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Groove is required on the bottom of the door, see mounting instructions for details.
Optional two-part floor guide can be purchased separately to avoid the need to cut a groove in the door.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Brand: Eclettica
Brand Model: Terno Eclettica
Detailed Door Movement: Single sliding
Door Height: 1 800 to 3 000 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 30 to 40 mm
Door Width: 740 to 1 250 mm
Function: Sliding Door
Groove Depth: 14 mm
Groove Needed for Guiding System: Yes
Groove Width at the Bottom of Door: 6 mm
Length - Overall Dimensions: 98 3/8 in*
Load Capacity: 66.1 to 110 lb*
Manufacturing Material: Aluminum
Number of Doors: 1
Overall Length: 2 500 mm
Product #: WEBKIT1243403
Product №: WEBKIT1243403
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: Two Soft-close
Soft- Closing: Yes
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Weight Capacity per Door: 30 to 50 kg
Resources
