Richelieu WEBKIT1243938 TERNO Accordion Folding Door SystemRichelieu WEBKIT1243938 TERNO ACCORDION Folding Door System is designed to accommodate multiple wood doors, each weighing up to 40 kg. This versatile top-hung center folding door system eliminates the need for a bottom guide channel, streamlining both installation and functionality. Available in 3-door and 4-door hardware sets, the system features surface-mounted hardware that allows for easy adjustments. The unique scissor-type hinges are mounted on both the top and bottom surfaces, ensuring smooth and reliable operation. The first panel is securely anchored with an upper pivot in the track and a lower pivot attached to the door jamb, providing stability and ease of use. Notably, the first panel is approximately half the width of the other folding doors, enhancing the design's flexibility. This folding door system is perfect for a range of applications, whether you're looking to divide a meeting room, office space, or classroom. It also excels in multi-purpose rooms, condominiums, restaurants, and kitchens transitioning into dining areas. For best results, remember to use metric dimensions during installation. With an overall length of 98 3/8 inches, and accommodating door heights from 39 3/8 to 106 inches, the Richelieu TERNO ACCORDION Folding Door System is an ideal solution for both residential and commercial spaces.
TERNO ACCORDION Folding Door System
The TERNO ACCORDION Folding Door System set for multiple wood doors weighing up to 40 kg each.
Features:
- Top hung center folding door system does not require a bottom guide channel
- Choice of 3-door and 4-door hardware sets
- Hardware can be surface mounted to the door
- Top and bottom surface mount scissor type hinges
- Simple to install that is easy to adjust
- First panel is anchored securely by an upper pivot mounted in the track and lower pivot mounted to the door jamb
- First panel is approximately half the door width of the other folding doors
An ideal solution for residential and commercial applications to divide a room or close a large opening. For Meeting Rooms, Office Space, Classrooms, Multi-Purpose Rooms, Common Area/Foyer in Condominiums, Restaurants and Kitchens to Dining Rooms.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Screen Panel
Bottom Guide: No
Brand: ACCORDION
Brand Model: Terno Accordion
Detailed Door Movement: Multi-Folding
Door Height: 1 000 to 2 700 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 30 to 45 mm
Door Width: 210 to 1 000 mm
Function: Bifolding Door
Length: 2 500 mm
Length - Overall Dimensions: 98 3/8 in*
Load Capacity: 44.1 to 88.2 lb*
Number of Doors: 3
Overall Length: 98 3/8 in*
Product #: WEBKIT1243938
Product №: WEBKIT1243938
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Ceiling Mount
Weight Capacity per Door: 20 to 40 kg
