Richelieu WEBKIT1243958 HAWA VARIOTEC 150H Multi-Door Sliding Partition SystemRichelieu WEBKIT1243958 HAWA VARIOTEC 150H Multi-Door Sliding Partition System offers an effective solution for creating versatile spaces in both commercial and residential environments. Designed to accommodate wood doors weighing up to 150 kg (330 lbs) each, this system is perfect for boardrooms, restaurants, banquet halls, and more. The HAWA VARIOTEC 150H features durable anodized tracks and guide channels that can be surface or recess mounted, allowing for a clean and sophisticated installation. With its flexible modular track system, you can create various parking configurations, from perpendicular to angled setups, providing tailored solutions for any space. The upper tracks, mounted with adjustable fixing plates, ensure optimal structural support. Ease of installation is a key benefit, thanks to service unit track end pieces that simplify the attachment of load trolleys. Optional curved track segments are available for custom directional changes, while locking options, including non-keyed and keyed deadbolts, enhance security. Brush and rubber seals are also available to improve environmental control. For projects requiring multiple door configurations, remember to specify the number of sliding and pivot door hardware sets needed. With technical support readily available, the HAWA VARIOTEC 150H stands out as a reliable choice for modern movable wall solutions.
HAWA VARIOTEC 150H Multi-Door Sliding Partition System
The HAWA VARIOTEC 150H is a multi-door sliding partition system for wood doors weighing up to 150 kg (330 lbs) each.
Features:
- All tracks and guide channels have a durable anodized finish
- Tracks can be surface and recess mounted
- Tracks can be cut and joined with standard couplers to create custom parking areas to stack doors and to extend track lengths for a smooth transition for upper trolleys
- Flexible modular track system with track segments makes a wide variety of parking configurations possible, from 90 degree/perpendicular to parallel, angled and even corner-turning configurations
- Service Unit track end pieces allow for simple installation of load trolleys and other components
- Adaptable to applications with or without bottom guide channels
- Upper tracks are mounted using adjustable fixing plates so that the track be fastened to the best structural support
- Optional curved track segments available via special order for changes in direction
- Locking options: non-keyed and keyed deadbolts, foot release levers
- Brush and rubber seals available
- Technical support available via email for calculating parking areas:
Canada:
[email protected] USA:
[email protected] IMPORTANT: You must individually add the number of Sliding Door and Pivot Door hardware sets needed for your project.
The HAWA VARIOTEC 150H Multi-Door Sliding Partition System is an ideal solution for multifunctional spaces in commercial and residential environments including board/meeting rooms, banks, store fronts, restaurants, banquet halls, and more.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Sliding Wall
Bottom Guide: No
Brand: Variotec
Brand Model: Hawa Variotec
Compatible with: Hawa Variotec
Detailed Door Movement: Stacking
Door Configurations: Parallel to upper track
Door Height: 59 to 157 in*
Door Installation: Top Hung
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 1 3/8 to 2 11/16 in*
Door Width: 897 to 1 000 mm
Finish: Anodized Aluminum
Length - Overall Dimensions: 24 ft*
Load Capacity: 88.2 to 331 lb*
Minimum Door Width: 33 1/2 to 59 in*
Number of Doors: 8
Overall Length: 7 315 mm
Product #: WEBKIT1243958
Product №: WEBKIT1243958
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Ceiling Mount
