Richelieu WEBKIT1248345 CS Ultimate Pocket Door Cavity Slider

Richelieu WEBKIT1248345 CS Ultimate Pocket Door Cavity Slider

Richelieu WEBKIT1248345 CS Cavity Slider Ultimate Pocket Door offers a robust solution for sliding wood doors, accommodating weights up to 500 lb (227 kg) each. Designed for standard 2 x 6 wood and metal wall stud construction, this pocket door system is ideal for both residential and commercial applications. You can select from a variety of pocket frames that fit door widths ranging from 30 in (762 mm) to 48 in (1219 mm) and heights up to 108 in (2743 mm), with special orders available for doors up to 60 in (1524 mm) wide and 120 in (3048 mm) tall. The sturdy double-wall aluminum frames include an adjustable upper running track that can be customized to suit your specific door dimensions. Installation is a breeze, as the frames arrive knocked down for cost-effective shipping. The innovative CarriSnap mounting suspension plate allows for effortless upper trolley mounting and release without tools. For added convenience, large wheel trolleys with precision ground bearings ensure a smooth operation. With features like a pivoting bottom guide and included trim clips for easy door jamb installation, the Richelieu CS Cavity Slider is a versatile choice for any project requiring seamless door movement.

CS Cavity Slider Ultimate Pocket Door

The CS Cavity Slider Ultimate Pocket Door Systems are for sliding wood doors weighing up to 500 lb (227 kg) each with options for SofStop soft-close mechanisms of up to 264 lbs (120 kg) per door. Made for standard 2 x 6 wood and metal wall stud construction.

Features:
- Choose from a selection of pocket frames for door widths from 30 in (762 mm) to 48 in (1219 mm) and for door heights of up to 108 in (2743 mm)
- Special order for doors up to 60 in (1524 mm) wide and 120 in (3048 mm) tall
- Pocket frames are made of sturdy double-wall aluminum, including the upper running track, which can be cut to size to suit custom size doors
- The frames are supplied knocked down for low-cost shipping and ease of installation
- Choose from a wide variety of carriage hardware sets with or without SofStop soft-close mechanism
- CarriSnap mounting suspension plate for the top of the door for mounting and releasing the upper trolley without tools
- SoftStop soft-close mechanisms come in single or twin action for doors weighing up to 176 lb (80 kg), and single action for doors weighing up to 264 lb (120 kg)
- Trim clips are included in the pocket frame sets for easy press-on mounting for door jamb trim
- Pivoting bottom guide to ease loading the door into the pocket frame during installation
- Large wheel trolleys with precision ground bearings for smooth running

For basic pocket door kits without soft-close, see the Suggested Products section below for a direct link to CS Cavity Slider Pocket Door Kit.

Ideal for residential, commercial, and institutional projects for a wide variety of applications.
