Richelieu WEBKIT1249726 AVENTOS HS Top Kit - CanadaRichelieu WEBKIT1249726 kits AVENTOS HS top -Canad offers a compact and innovative solution for managing large doors with ease. Designed specifically for single-piece facades, this system ensures smooth and effortless operation, allowing doors to tilt gracefully above the cabinet. This design creates a weightless sensation, providing unparalleled freedom of movement without interrupting your workspace. With the capability to accommodate cabinet heights ranging from 350 to 800 mm (13 3/4 in - 31 1/2 in) and widths up to 1,800 mm (70 7/8 in), the AVENTOS HS top is perfect for a variety of applications. It requires a minimum interior cabinet depth of 264 mm (10 3/8 in), making it versatile for most installations. Key features include integrated BLUMOTION damper adjustment for minimal resistance forces, a continuous stop for stability, and tool-free assembly for quick installation. The symmetrical force reservoirs and arms ensure balanced operation, while the 3-dimensional face adjustment allows for perfect alignment. For thinner facades, consider the additional 20S42T1 front attachment. Maximize your storage capacity and optimize space with the Richelieu AVENTOS HS top, a perfect blend of functionality and modern design.
kits AVENTOS HS top -Canad -
A compact and functional solution for large doors
Designed for large, single-piece facades, AVENTOS HS top ensures smooth and effortless opening. The door tilts gently above the cabinet, offering a weightless sensation and unparalleled freedom of movement.
Product highlights:
- Ideal for large single-piece facades
- Cabinet height from 350 to 800 mm (13 3/4 in - 31 1/2 in)
- Cabinet width up to 1,800 mm (70 7/8 in)
- Minimum interior depth of cabinet body: 264 mm (10 3/8 in)
- Integrated BLUMOTION damper adjustment
- Minimal resistance forces
- Continuous stop
- Fixed position for the force reservoir and front attachment
- Symmetrical force reservoirs and arms
- Tool-free assembly
- Two types of force reservoir mounting
- 3-dimensional face adjustment
Thanks to its opening outside of the movement range, access to the interior is complete, without encroaching on workspace. Without a cross stabilizer, it maximizes storage capacity while seamlessly integrating into designs for optimized space and controlled ergonomics.
For thin facades, use the 20S42T1 front attachment, which can be found among the suggested products.
Attributes
Brand: Blum
Compatible with aluminum frame doors: Yes
Door Height: 18 7/8 to 26 in*
Door Length: Max. 70 7/8 in*
Door Type: Wood Door / Wide Aluminum-Framed Door
Door Weight: 6.06 to 33.6 lb*
Finish: Silk White
Minimum internal depth of the enclosure: Min. 10 3/8 in*
Model: Aventos HS Top
Opening Types: Up and Over Opening
Product #: WEBKIT1249726
Screw/ Nail: Pre-Mounted Euro Screw
