Richelieu WEBKIT1249740 AVENTOS HS Top Kit - USARichelieu WEBKIT1249740 kits AVENTOS HS top -USA - offers a compact and functional solution specifically designed for large, single-piece doors. Ideal for cabinets ranging from 350 mm (13-3/4 in) to 800 mm (31-1/2 in) in height, this system accommodates widths up to 1828 mm (72 in), and requires a minimum internal depth of 264 mm (10-3/8 in). The innovative design allows the door to tilt smoothly above the cabinet, providing a weightless sensation and effortless access to the interior without encroaching on your workspace. Equipped with integrated BLUMOTION, the AVENTOS HS top ensures soft and gentle closing, while the light operating forces and variable stop enhance user experience. This system features a fixed position for the lift mechanism and door mounting plate, symmetrical levers, and tool-free assembly for quick installation. The two lift mechanism fixing methods and 3-dimensional door adjustment further enhance functionality. For enhanced versatility, a front attachment for thin facades is available (20S42T1). With its seamless integration into designs, the AVENTOS HS top maximizes storage capacity while promoting ergonomics in any space. Transform your cabinetry with this exceptional lift system from Richelieu, delivering both style and practicality.
kits AVENTOS HS top -USA -
A compact and functional solution for large doors
Designed for large, single-piece facades, AVENTOS HS top ensures smooth and effortless opening. The door tilts gently above the cabinet, offering a weightless sensation and unparalleled freedom of movement.
Product highlights:
- Ideal for large, one-part doors
- Cabinet height 350 (13-3/4 in) to 800 (31-1/2 in)
- Cabinet width up to 1828 (72 in)
- Inside depth of at least 264 (10-3/8 in)
- Integrated BLUMOTION for soft and effortless closing
- Light operating forces
- Variable stop
- Fixed position of the lift mechanism and door mounting plate
- Symmetrical levers
- Tool-free assembly
- Two lift mechanism fixing methods
- 3-dimensional adjustment of the door
Thanks to its opening outside of the movement range, access to the interior is complete, without encroaching on workspace. Without a cross stabilizer, it maximizes storage capacity while seamlessly integrating into designs for optimized space and controlled ergonomics.
For thin facades, use the 20S42T1 front attachment, which can be found among the suggested products.
Attributes
Brand: Blum
Door Height: 13 3/4 to 17 5/8 in
Door Length: Max. 72 in*
Door Type: Wood Door / Wide Aluminum-Framed Door
Door Weight: 4.38 to 26.56 lb
Finish: Pale Grey
Minimum internal depth of the enclosure: Min. 10 3/8 in*
Opening Types: Up and Over Opening
Product #: WEBKIT1249740
Screw/ Nail: Wood Screw (Included)
