Richelieu WEBKIT1257103 HAWA JUNIOR 250A SystemRichelieu WEBKIT1257103 HAWA JUNIOR 250 A System is engineered for heavy sliding wood doors or walls, accommodating weights up to 250 kg (551 lb) each. This top-hung sliding system offers a robust surface-mounted suspension plate that ensures stability and smooth operation, making it suitable for various applications, including residential, commercial, and institutional projects. Designed for door thicknesses ranging from 35 to 80 mm (1-3/8" to 3-1/8"), the anodized upper track can be easily surface mounted or recessed into the ceiling, providing flexibility in installation. For longer spans, the track can be joined using connecting pins (model 8921347140). The system features a track stopper with a damper and adjustable retention spring, effectively minimizing door bounce-back for a refined user experience. The HAWA JUNIOR 250 A allows for straight sliding and bypassing movements, accommodating door heights from 70 7/8 to 157 inches and widths from 59 to 118 inches. A groove must be machined into the bottom of the door to facilitate a rattle-free floor guide, ensuring seamless operation. Please note that metric dimensions are recommended for enhanced installation accuracy. With its robust construction and thoughtful design, this sliding system is a reliable choice for any project.
HAWA JUNIOR 250 A System
Designed for heavy sliding wood doors or walls weighing up to 250 kg (551 lb) each, the HAWA JUNIOR 250 A System is a top-hung sliding system equipped with a surface-mounted suspension plate at the top of the door.
Features:
- For door thickness of 35 to 80 mm (1-3/8" to 3-1/8")
- Anodized upper track can be surface mounted or recessed into the ceiling
- Upper track can be joined with connecting pins 8921347140 for long lengths
- Track stopper with damper and adjustable retention spring resists door bounce-back
This is an ideal solution for residential, commercial, and institutional projects.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
A groove must be machined into the bottom of the door for a rattle-free floor guide.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Brand: Hawa
Detailed Door Movement: Bypassing
Door Height: 70 7/8 to 157 in*
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 1 25/32 to 31 1/2 in*
Door Width: 59 to 118 in*
Groove Depth: 1 3/32 in*
Groove Needed for Guiding System: Yes
Groove Width at the Bottom of Door: 21/32 in*
Load Capacity: 331 to 551 lb*
Number of Doors: 2
Overall Length: 13 ft 1 in*
Product #: WEBKIT1257103
Roller Position: Upper
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Stopper: Two
Track Mounting: Ceiling Mount
