Richelieu WEBKIT1257148 HAWA JUNIOR 120 GP Sliding Door SystemRichelieu WEBKIT1257148 HAWA JUNIOR 120 GP System offers a robust solution for sliding glass doors, accommodating weights of up to 120 kg (264 lb) with ease. This top-running sliding system features a secure clamp-patch fitting, designed for solid or multi-layer glass with thicknesses ranging from 8 to 12.7 mm (5/16 in to 1/2 in). Flexibility is key with track options that include surface or recessed anodized ceiling tracks, as well as a removable track for pocket door applications. The system also provides customizable aesthetics with round or square cover caps available in Satin Silver, Brushed Stainless Steel Look, and Chrome Plated finishes. Enhanced functionality is achieved with the SoftStop track stopper, which incorporates a soft-close mechanism and an adjustable retention spring to prevent door bounce back. This system is ideal for various settings including kitchens, offices, consultation rooms in medical facilities, and residential spaces. For optimal results, it’s important to adhere to metric dimensions during installation, and the glass must be drilled according to the specific instructions for the clamp patch fitting. With a minimum door width of 850 mm (33 3/8 in) for soft close on one side, this system ensures a seamless experience for both professionals and homeowners alike.
HAWA JUNIOR 120 GP System
The HAWA JUNIOR 120 GP System is for sliding glass doors weighing up to 120 kg (264 lb) each. This is a top-running sliding system equipped with a secure clamp-patch fitting for solid or multi-layer glass up to 12.7 mm (1/2 in) thick.
Features:
- For glass thickness of 8 to 12.7 mm (5/16 in to 1/2 in)
Track options:
- Surface or recessed anodized ceiling track
- Removable track for pocket door applications
- Wall mount profile
- Round or square cover caps for clamp patch fitting are available in Satin Silver, Brushed Stainless Steel Look, and Chrome Plated finishes.
- SoftStop track stopper with soft-close mechanism and adjustable retention spring resists door bounce back
An ideal solution for residential, commercial, and institutional projects, suitable for for kitchens, offices, examination and consultation rooms in medical clinics, meeting rooms, bedrooms, and washrooms.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Glass must be drilled as per instructions for clamp patch fitting.
Minimum door width 850 mm (33 3/8 in) for soft close on one side and minimum 1150 mm (45 1/4 in) for soft close on both sides.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Barn Door
Detailed Door Movement: Single sliding
Door Height: 47 1/4 to 157 in*
Door Installation: Top Hung
Door Material: Glass
Door Movement: Straight Sliding
Door Width: 39 3/8 to 78 3/4 in*
Finish: Matte Chrome
Glass Thickness: 5/16 to 1/2 in*
Load Capacity: 176 to 265 lb*
Number of Doors: 1
Overall Length: 13 ft 1 in*
Product #: WEBKIT1257148
Roller Position: Upper
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: Yes
Stopper: Two
Track Mounting: Wall Mount
