Rutherford Controls EM-MAG1500 Slim-Line Electromagnetic Lock

Rutherford Controls EM-MAG1500 Slim-Line Electromagnetic Lock offers a compact and effective solution for securing outswinging doors and small enclosures. This innovative electromechanical lock is designed to be significantly smaller than standard electromagnetic locks, making it an ideal choice for spaces where traditional options may be too bulky. The EM-MAG1500 features a bi-color light panel that clearly indicates lock status, along with an early warning alarm to enhance security. Its robust design includes an anti-tamper security plate, ensuring added protection against unauthorized access. With a holding force of 1,500 lbf and the ability to release under a side load of up to 130 lbs, this lock is both powerful and reliable. Constructed from anodized aluminum and zinc-plated for corrosion resistance, the EM-MAG1500 is built to withstand the test of time. It operates with low energy consumption, drawing only 240 mA at 12VDC or 120 mA at 24VDC. Additionally, it has been factory tested to exceed one million cycles, ensuring longevity and performance. With dimensions of 6-7/32" width, 1-7/16" height, and 1-3/8" depth, the EM-MAG1500 is easy to install while providing essential access control features. Backed by a 3-year limited warranty, it’s a smart investment for your security needs.

Slim-Line Electromagnetic Lock

The EM-Mag1500 compact electromechanical lock is designed for outswinging doors and small enclosures. The RCI EM-Mag1500 is significantly smaller than standard electromagnetic locks. This electromechanical solution includes a bi-color light panel for indicating lock status, an early warning alarm, and an anti-tamper security plate.

Features:

• Slim design; significantly smaller than standard electromagnetic locks
• Bi-color light panel indicates lock status
• Releases under side load of up to 130lbs (60kg)
• Early warning alarm
• Includes anti-tamper security plate
• Anodized aluminum housing; zinc plated for anti-corrosion
• No residual magnetism
• Low energy consumption
• Factory tested to over 1-million cycles
• Energy: 240mA Field-selectable 12/24VDC (At 12VDC, 120mA at 24VDC)
• Strength: 1,500lbf Holding force
• Mode: Fail-safe
• Monitor: Lock & door status sensors
• 3 Year limited warranty

Technical Details:

• Dimensions: 6-7/32"W x 1-7/16"H x 1-3/8"D (158mm x 36mm x 35mm)
• Armature Plate: 4-3/4"W x 1-3/16"H x 1/2"D (121mm x 30mm x 12.5mm)
• Applications: Outswing doors & small enclosures
