Rutherford Controls P-620-H-A Mullion Mount Keypad / Prox Reader

Rutherford Controls P-620-H-A Mullion Mount Keypad / Prox Reader sets the standard in electronic security with its advanced 125 kHz proximity technology. Designed for seamless integration with various access control systems, this keypad reader supports both legacy Wiegand and the more modern bi-directional Open Supervised Device Protocol (OSDP). Its sleek dimensions of 1.78" W × 6.1" H × 0.91" D make it an ideal choice for both interior and exterior applications across retail, commercial, industrial, educational, and healthcare settings. Weighing only 4 oz, the P-620-H-A offers impressive functionality with a typical current draw of 70 mA and a peak of 110 mA at 12 VDC. It operates efficiently within a voltage range of +5 to 16 VDC. The device features a four-state LED indicator (red, green, amber, and off) for clear user feedback. Certified by FCC, ICC, CE, C-Tick, UL Standard 294, and ULC 60839-11-1, this weatherproof reader boasts an IP67 rating, ensuring durability in diverse environments. The P-620-H-A is equipped with a 12-button illuminated keypad, providing reliable access control with a read range of up to 7 inches, making it a versatile choice for any security setup.

Mullion Mount Keypad / Prox Reader

RCI Pyramid P-620-H-A and P-640-H-A sets the electronic security benchmark for 125kHz proximity keypad readers. Based upon proven contactless digital radio frequency identification (RFID) technology, RCI Pyramid readers interface with a wide range of electronic access control systems by complying with either the legacy Wiegand or the latest bi-directional open supervised device protocol (OSDP). They offer value-add features such as MAXSecure, fleaPower and can support several proximity card and tag technologies.

Technical Details:

• Technology: 125 kHz standard security mullion keypad reader
• Dimensions: 1.78" W × 6.1" H × 0.91" D (45 mm × 155 mm × 23 mm)
• Weight: 4 oz (113 g)
• Current draw: 70 mA typical, 110 mA peak @ 12 VDC
• Voltage: +5 to 16 VDC
• LED: Four-state standard (red, green, amber, and off)
• Certifications: FCC, ICC, CE, C-Tick, UL Standard 294, ULC 60839-11-1
• Keypad output: 8-Bit Burst; 26-bit Wiegand standard
• Applications: These readers are suitable for interior or exterior doors and entrance systems in virtually all applications Retail and Commercial; Industrial; Education, Healthcare facilities and more.

Features

• Weight: 4 oz (113 g)
• LED: Four-state standard (red, green, amber, and off)
• Certifications: FCC, ICC, CE, C-Tick, UL Standard 294, ULC 60839-11-1
• Voltage: +5 to 16 VDC
• Applications: These readers are suitable for interior or exterior doors and entrance systems in virtually all applications Retail and Commercial; Industrial; Education, Healthcare facilities and more.
• Current draw: 70 mA typical, 110 mA peak @ 12 VDC
• Dimensions: 1.78" W × 6.1" H × 0.91" D (45 mm × 155 mm × 23 mm)
• Keypad output: 8-Bit Burst; 26-bit Wiegand standard
• Technology: 125 kHz standard security mullion keypad reader
