Rutherford Controls YD30D Electronic Side Load Lock for Double Swing Doors (180 Degree)

Rutherford Controls YD30D Electronic Side Load Lock for Double Swing Doors (180 Degree) is a robust motor-driven locking solution designed to enhance security for both commercial and residential applications. This versatile lock excels in controlling access for single and double-acting doors, making it an ideal choice for high-traffic environments. With a remarkable holding force of 2204 lbs (1000 kg) and the ability to handle sideloads of 1322 lbs (600 kg), the YD30D ensures that your doors remain secure under various conditions. Notably, this lock features automatic deadbolting, providing an extra layer of security and convenience. The YD30D is also equipped with door misalignment correction capabilities of up to 16mm, ensuring seamless operation even in challenging installations. This electronic lock operates on a low voltage of 12-24 VDC and is easily integrated with access control systems, making it suitable for both mortise and surface installations. The user-selectable fail safe and fail secure modes add flexibility, allowing for customization based on specific security needs. Furthermore, the YD30D meets various certifications, including UL and CE, ensuring reliability and compliance with industry standards. With a warranty of three years and an endurance rating of one million operations, the Rutherford Controls YD30D promises long-lasting performance for your security needs.

Electronic Side Load Lock for Double Swing Doors (180 Degree)

The YD30 series electronic locks are motor driven electronic locks designed to secure commercial and residential single and double acting doors. The YD30 series gives the user the ability to control access in and around a facility and provide traffic reports when desired. Additionally, the YD30 series can be used in a more straightforward system where controlling access to a single door can be implemented with a stand-alone RTE access system. A high traffic, low voltage, motor-driven door lock. YG30 series are typically activated by access control systems and used in commercial entrance doors in either mortise or surface installation as well as swing-through glass doors where security is paramount, convenience required, and appearances important.

Features:

• Correcting door misalignment of up to 16mm (+/-8 mm)
• Door will still release with excess of 1322 lbs (600kg) applied force
• Automatic deadbolting
• 2204 lbs (1,000 Kg) holding force
• 10mm thick stainless steel bolt pins
• User selectable fail safe and fail secure
• Assist with door alignment
• Automatic deadbolting providing high security
• Easily converts from fail safe to fail secure
• Versatile installation

Technical Details:

• YD30D: 10" x 1-1/4" x 1-7/8" (255 x 30 x 47mm)
• Energy: 12-24 VDC 40mA@12VDC, 25mA@24VDC; Peak: 0.75A@12VDC, 0.4A@24VDC
• Strength 2204lbs (1000kg) holding force; 1322lbs (600kg) sideload
• Warranty: 3 years
• Endurance: 1 million operations
• Mode: Fail Safe/Fail Secure selectable
• Monitoring: Door and bolt positions
• Certifications: CE, RoHS 2, FCC Part 15 / IC RCM, UL Listed EN 14846:2008 Certified Suitable for use on fire resistant doors (UL 10C; 3 hrs)
• UL10C For use in vertical orientation with any UL swinging type fire door frame rated up to and including 3 hours
