Rutherford Controls YD30S Electronic Side Load Lock for Single Swing Doors (90 Degree)

Rutherford Controls YD30S Electronic Side Load Lock for Single Swing Doors (90 Degree) is engineered for both commercial and residential applications, providing robust security for single and double acting doors. This motor-driven electronic lock enhances access control, offering flexibility for high-traffic environments. The YD30S supports straightforward installation with a stand-alone RTE access system, ensuring secure operation while maintaining aesthetic appeal. Featuring an impressive holding force of 2204 lbs (1000 kg) and the capability to correct door misalignment of up to 16mm (+/- 8mm), this lock is built for resilience. It automatically deadbolts, enhancing security, and can withstand excessive force of 1322 lbs (600 kg) while still allowing the door to release. The lock's operation mode is user-selectable between fail safe and fail secure, providing adaptable security options. Constructed with 10mm thick stainless steel bolt pins, the YD30S is designed for durability and longevity, boasting an endurance of over 1 million operations. It also includes door and bolt position monitoring for added peace of mind. Certified for use on fire-resistant doors (UL 10C; 3 hrs), this lock is a reliable choice for demanding security needs in various settings.

Electronic Side Load Lock for Single Swing Doors (90 Degree)

The YD30 series electronic locks are motor driven electronic locks designed to secure commercial and residential single and double acting doors. The YD30 series gives the user the ability to control access in and around a facility and provide traffic reports when desired. Additionally, the YD30 series can be used in a more straightforward system where controlling access to a single door can be implemented with a stand-alone RTE access system. A high traffic, low voltage, motor-driven door lock. YG30 series are typically activated by access control systems and used in commercial entrance doors in either mortise or surface installation as well as swing-through glass doors where security is paramount, convenience required, and appearances important.

Features:

• Correcting door misalignment of up to 16mm (+/-8 mm)
• Door will still release with excess of 1322 lbs (600kg) applied force
• Automatic deadbolting
• 2204 lbs (1,000 Kg) holding force
• 10mm thick stainless steel bolt pins
• User selectable fail safe and fail secure
• Assist with door alignment
• Automatic deadbolting providing high security
• Easily converts from fail safe to fail secure
• Versatile installation

Technical Details:

• YD30S: 6-1/4" x 1-1/4" x 1-7/8" (160 x 30 x 47mm)
• Energy: 12-24 VDC 40mA@12VDC, 25mA@24VDC; Peak: 0.75A@12VDC, 0.4A@24VDC
• Strength 2204lbs (1000kg) holding force; 1322lbs (600kg) sideload
• Warranty: 3 years
• Endurance: 1 million operations
• Mode: Fail Safe/Fail Secure selectable
• Monitoring: Door and bolt positions
• Certifications: CE, RoHS 2, FCC Part 15 / IC RCM, UL Listed EN 14846:2008 Certified Suitable for use on fire resistant doors (UL 10C; 3 hrs)
• UL10C For use in vertical orientation with any UL swinging type fire door frame rated up to and including 3 hours
