Sargent KP-10XG77-LL-10BE Stand Alone Keypad 10X Line Storeroom Lock offers robust security with the convenience of keypad access for up to 100 users. Designed for easy installation and operation, this battery-powered lock utilizes a microprocessor-based controller with non-volatile memory, ensuring reliable performance in various settings. The ANSI/BHMA Grade 1 rating guarantees high-quality hardware, making it suitable for demanding environments. This lock features a textured, ultraviolet stable keypad that provides clear LED indicators: green for unlocked, yellow for programming mode, and a combination indicating the deadbolt's status. With an impressive lifespan of approximately 40,000 operations per battery set, the KP-10XG77 is both efficient and economical. It supports standalone entry capabilities while allowing integration into new or existing master keyed systems. The lock’s functionality includes a key override for added security, while the guardbolt deadlocks the latch for enhanced protection. Its 2-3/4 inch backset and 1/2 inch latchbolt throw make it versatile for various door types. Additionally, the option for privacy capabilities makes it ideal for restrooms or restricted areas. Finished in a sophisticated Dark Satin Bronze (613E/US10BE), this lock seamlessly blends security with aesthetics, making it an excellent choice for any facility.

Stand Alone Keypad 10X Line Storeroom Lock, 100 Users, Battery Powered, Keypad Programming, Grade 1, 808 ANSI Strike, LA Keyway 1-Bitted, 2-3/4in Backset, 613E/US10BE Dark Satin Bronze

The KP-10X line keypad locks utilize our ANSI/BHMA grade 1 bored lock and are designed for openings that require standalone, basic authorized entry capabilities. They are battery powered, motor driven, self contained locks that use a microprocessor based controller with non-volatile memory. All programming is done at the door using the keypad with functions selected by the user according to opening requirements and with the cylinder override feature, the keypad lock can be readily integrated into a new or existing master keyed system.

Features:

• Non-volatile memory
• Quick and easy installation
• Keypad made of ultraviolet stable textured material
• Integrated ANSI/BHMA grade 1 hardware
• LED indicators on Keypad where green indicated unlocked, yellow indicates programming mode, and flashing green/solid yellow indicates deadbolt thrown
• Typical 40,000 operations per set of batteries
• Available with cylinder override
• All programming is done at the door using the keypad with functions selected by the user according to opening requirements
• Designed for openings that require standalone and basic authorized entry capabilities
• The keypad lock can be readily integrated into a new or existing master keyed system
• Assurance of high quality hardware allows the flexibility to support various openings
• Offers privacy capabilities for applications such as restrooms

Specifications:

• ANSI/BHMA Grade: A156.2
• Latchbolt Throw: 1/2"
• Lock Type: Cylindrical Lock

Function:

• Key outside always retracts latch
• Lever outside rigid except when valid credential presented
• Lever inside always retracts latch
• Guardbolt deadlocks latch
• Key override standard with #C10X-E1 cylinder supplied
• Low battery (for IN120), request-to-exit (REX), door position (DPS), and tamper signaling standard
• Door position switch (DPS, P/N 52-5373) supplied

Mechanical Options:

• 12- Fire Rated: UL Fire label exit hardware (KP-8800 & KP-8900 series Exits Only) (not available with 16-)
• 16- Cylinder Dogging: Cylinder rail dogging with # 41 cylinder (not available with 12-, 59- or AL- option) (KP8800 & KP8900 series exits) (KP-8800,KP-8900 series exits only)
• 19- Less Touch Pad: Pushbar without Lexan touchpad (KP-8800 & KP-8900 Series exits only)
• 23- Flat Lip Strike: Flat 4-7/8" (124mm) ANSI strike (KP8200 series mortise)
• 23- Backset Options: 3-3/4" (95mm) Backset (for KP10XG77 only)
• 25- Backset Options: 5" (127mm) Backset (for KP10XG77 only)
• 29- Strike: Strike #800. Lip length 1-1/4". Lip lengths 1" to 2" in 1/4" increments only.
• 36- Security Fasteners: Six lobe security head screws
• 37- Security Fasteners: Spanner head screws
• 41- Double Doors: 3/4" Throw latchbolt x 2-3/4" backset
• 75- Tactile Warning Options: Tactile warning - milled inside lever (not available with exit devices, studio & coastal levers and the A lever)
• 76- Tactile Warning Options: Tactile warning - milled outside lever (not available with studio & coastal levers and the A lever)
• 77- Tactile Warning Options: Tactile warning - milled inside & outside lever (not available with exit devices, studio & coastal levers and the A lever)
• 85- Tactile Warning Options: Tactile warning - abrasive coating on inside lever (or push rail for exits)
• 86- Tactile Warning Options: Tactile warning - abrasive coating on outside lever
• 87- Tactile Warning Options: Tactile warning - abrasive coating on outside lever & inside lever (or push rail for exits)
• CPC- Finish Options: Clear powder coat (available for 26, 26D, 32 & 32D finishes) (KP-8800,KP-8900 series exits only)
• SG- Finish Options: MicroShield antimicrobial clear powder coat (available with 15, 26D, and 32D finishes)
• 18- Misc. Options: Dogging indicator (KP-PE8800, PE8900 series exits only)
• WR- Misc. Options: Wire routing (KP-PE8800, PE8900 series exits only)
• FW- Misc. Options: Freewheeling locking levers

Finishes:

• 03/605 - Bright brass
• 04/606 - Satin brass
• 09/611 - Bright bronze
• 10/612 - Satin bronze, clear powder
• 10B/613 - Oxidized satin bronze oil rubbed
• 10BE/613E - Dark Oxidized Satin Bronze — equivalent
• 10BL - Oxidized satin bronze, clear powder coat
• 14/618 - Bright nickel, clear coated
• 15/619 - Satin nickel, clear coated
• 26/625 - Bright chrome
• 26D/626 - Satin chrome
• 32/629 - Bright stainless steel
• 32D/630 - Satin stainless steel
• BSP - Black suede powder coat
• WSP - White suede powder coat
