Sargent RX-8273-12V 26D Electrified Mortise Body

Sargent RX-8273-12V 26D Electrified Mortise Body delivers exceptional security and reliability with its electro-mechanical fail-secure function. Designed for double-cylinder use, this lock operates at 12 volts and features a sleek satin chrome finish that seamlessly integrates into various architectural styles. Crafted with high-quality components, the RX-8273 stands out as a benchmark in the industry, showcasing a robust 12-gauge heavy-duty wrought steel case and stainless steel latchbolt that offers a ¾ inch projection. Its adjustable outside front plate accommodates doors with a thickness of 1-3/4 inches, and it can be customized for thicker doors upon specification. This lock is built to endure, with features including high carbon steel springs and a one-piece hardened stainless steel deadbolt for added security. The Sargent RX-8273 includes masterkeying options and a variety of finishes, ensuring it meets specific project requirements. With a limited warranty of two years for electrified locks, it stands as a trusted choice for professionals seeking durability and innovation. Ideal for high-traffic areas where security is paramount, the Sargent RX-8273-12V offers the perfect balance of strength, flexibility, and cutting-edge technology to safeguard your property.

Electrified Mortise Body

Lock Body Only, Electro Mechanical Fail Secure Function, Double Cylinder, Request to Exit, 12 Volt, Satin Chrome

Designed and constructed with high quality components to provide maximum security.

 The Sargent electrified 8270 series locks represent over a century of innovation and experience in manufacturing hardware and are the industry’s benchmark for mortise locks: Strong - Durable - Flexible – Innovative and Secure.

• For Doors 1-3⁄4" (44mm) thick standard. For doors over 1-3⁄4" (44mm), specify door thickness and panels (if any)
• Backset 2-3⁄4" (70mm) only
• Case 12 gauge heavy duty wrought steel, zinc dichromate plated. Thickness 7/64" (3mm) (.109")
• Outside Front Plate Brass, bronze or stainless steel. 8" (203mm) x 1-1⁄4" (31mm), ANSI Standard A115.1. Adjustable at any angle from flat to beveled 1⁄8" (3mm) in 2" (51mm)
• Springs High carbon steel
• Hubs for Knobs Sintered iron copper infiltrated
• Hubs for Levers Cold forged steel
• Hubs for Institutional Stainless steel (3- prefix)
• Latchbolt Stainless steel 3⁄4" (19mm) projection one-piece, anti-friction reversible latch
• Auxiliary Deadlatch Stainless steel, non-handed
• Deadbolt One-piece hardened stainless steel, with 1" (25mm) projection
• Hand Specify hand on order; easily field reversible (if no hand is specified RH will be provided)
• Strike Brass, bronze or stainless steel; ANSI Standard A115.1; curved lip, non-handed (strike box optional)
• Keys Two, nickel silver (control key or emergency key must be ordered when required)
• Cylinder Brass, size #41 (1-1/8") standard (except for Freewheeling, size #46 (1-3/4")). Available with SARGENT Signature, V-10, XC and KESO Security Systems
• Masterkeying Can be masterkeyed or grand masterkeyed. Construction keying available. LA standard keyway.
• Finishes 3, 4, 9, 10, 10B, 10BL,15, 20D, 26, 26D, 32, 32D Special finishes are available. (Contact factory for details)
• Classroom Security 38, 39, 40, 41 Functions (All mortise trim designs available except KE/LE 3 & 4 and PT trim or FE trim with 41 function)
• Stile 4-1/2" (114mm) minimum stile for 7800/8200, 4-3/4" (121mm) minimum stile for electrical function locks
• Door Prep ANSI A115.1 modified per template (see template for 7800/8200 lockbody & trim)
• Warranty 10 year limited warranty, 2 year limited warranty on electrified locks
