Ship via: Can Ship UPS
Manufacturer surcharge: 4.5%
Ansi Function: E0152 - Single Cylinder Deadbolt
Backset: Adjustable Backset 2-3/8" and 2-3/4"
Bolt Projection: 1 In.
Bolt Protection: 1 In.
Commercial Residential: Commercial
Cylinder Type: SFIC Prep Less Core
Door Thickness: 1-5/8 In. - 2 In.
Dust Box: None
Finish: 612/US10
Finish Description: Satin Bronze Clear Coated
Function: 560-Single Cylinder Deadbolt Lock
Grade: Grade 3
Installation: Commercial
Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.
Latch Number: 12-288
Latch Type: Deadbolt
Lock Face Size: 2-1/4 In. x 1 In.
Pack Height: 3"
Pack Length: 5.75"
Pack Qty: 1
Pack Width: 4.5"
Pbs Options: 220322805
Series: B500 Series Deadbolts
Ship Weight: 2 lbs.
Std Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.
Std Latch Number: 12-287
Std Latch Type: Deadbolt
Std Strike Height: 2-3/4 In.
Std Strike Number: 10-094
Std Strike Type: Flat
Std Strike Width: 1-1/8 In.
Strike: Square Corner Deadbolt Strike
Strike Height: 2-3/4 In.
Strike Number: 10-094
Strike Type: Flat
Strike Width: 1-1/8 In.
Subtype: Deadbolts
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Upc: 043156132560
