Attributes
Manufacturer surcharge: 3.5%
Alternate Codes: 141507, B560B605, B560BD605, SCHB560BD605
Ansi Function: E0152 - Single Cylinder Deadbolt
Backset: 2-3/8"-2-3/4"
Bolt Projection: 1 In.
Bolt Protection: 1 In.
Category: Commercial Deadbolts, Commercial Locks, Deadbolts, Lock Sets, Single Cylinder, Single Cylinder (Commercial)
Commercial Residential: Commercial
Cylinder Included: No
Cylinder Type: SFIC Cylinder
Deadbolt Functions: Single Cylinder x Thumb Turn
Deadbolt Type: Commercial
Door Application: Commercial Deadbolts
Door Bore Size: 2-1/8"
Door Thickness: 1-5/8 In. - 2 In.
Door Thickness Max: 1-7/8"
Door Thickness Min: 1-3/8"
Dust Box: None
Faceplate Style: Circular Drive-In, Radius Corner, Square Corner
Finish: 605/US3
Finish Code: US3
Finish Color: Polished Brass
Finish Description: Bright Brass
Function: 560-Single Cylinder Deadbolt Lock
Grade: Grade 2
Handing: Non-Handed
Installation: Commercial
Keyway Brand: Schlage
Knob/ Lever Style: Inside Thumbturn
Language: English
Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.
Latch Bolt Face Type: Drive-In, Radius Corner, Square Corner
Latch Bolt Faceplate Size: 1" x 2-1/4"
Latch Bolt Throw: 1"
Latch Bolt Type: Deadbolt
Latch Number: 12-288
Latch Type: Deadbolt
Latchbolt Type: Deadbolt
Lock Category: Deadbolts
Lock Face Size: 2-1/4 In. x 1 In.
Pack Height: 3"
Pack Length: 5.75"
Pack Qty: 1
Pack Width: 4.5"
Pbs Options: 220322805
Series: B500 Series
Ship Weight: 2 lbs.
Std Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.
Std Latch Number: 12-287
Std Latch Type: Deadbolt
Std Strike Height: 2-3/4 In.
Std Strike Number: 10-094
Std Strike Type: Flat
Std Strike Width: 1-1/8 In.
Strike: Square Corner Deadbolt Strike
Strike Height: 2-3/4 In.
Strike Number: 10-094
Strike Size: 2-3/4" x 1-1/8"
Strike Type: Flat
Strike Width: 1-1/8 In.
Subtype: Deadbolts
Supplier: Schlage
Type: LOCK SETS
Unit of Measure: Each
