Schlage B62N-625 12-287 Grade 1 Double Cylinder Deadbolt, 5-Pin C Keyway, Adjustable Backset, Chrome

Schlage Lock Company B62N-625 12-287 Deadbolt Double Cylinder combines robust security with thoughtful design, making it an ideal choice for residential applications. This Grade 1 deadbolt features a 5-pin Schlage "C" keyway and is available with a sleek bright chrome finish. The double cylinder design allows for key operation from both sides, enhancing security in areas where a standard thumb turn may be accessible to intruders. Engineered for ease of installation, the B62N-625 incorporates a triple option adjustable backset that accommodates 2-3/8" to 2-3/4" door frames, and its innovative 3-piece assembly simplifies the setup process. The anti-pick shield offers additional resistance against tampering, while the increased bolt size provides exceptional kick-in resistance. Designed for doors ranging from 1-3/8" to 1-3/4" thick, this deadbolt requires a 1" door prep for the larger bolt housing. The larger thumb turn is ADA compliant and ensures a comfortable grip, while contoured edges add an aesthetic touch. With keying options that include keyed alike and master keyed configurations, the Schlage B62N-625 is not only secure but also versatile, meeting the needs of both homeowners and building professionals alike.

Deadbolt Double Cylinder, Grade 1, 5-Pin C Keyway KD, Triple Option Adjustable Backset 2-3/8 to 2-3/4, 625/US26 Bright Chrome

The B60 deadbolt is a new grade 1 residential deadbolt from Schlage. Designed with input from locksmiths, professional installers, builders and distributors the B60 series deadbolt offers enhanced grade 1 security, faster & easier installation via it's 3-piece assembly and "snap & stay" feature for hands-free installation, and a sleek low-profile design plus newly designed interior thumbturn, which is larger and easier to grip as well as ADA compliant. BHMA grade 1 product performance. Increased latch/bolt size offers maximum kick-in resistance. Anti-pick shield. 3-piece assembly. Contoured edges for added style. Low-profile face cannot be unscrewed and is impossible to grab with a wrench. Adjustable backset (2-3/8" or 2-3/4") has the industry's only helical design that locks into place with no adjusting during installation.

Specifications:

• Door Range: 1-3/8" - 1-3/4" (35mm - 44mm).
• Backset: Dual backset latch; adjustable for 2-3/8" or 2-3/4" backset.
• Door Prep: Required 1" door prep for larger bolt housing.
• Latch: 1" x 2-1/4" (25mm x 57mm) Round Corner, 1" (25mm) housing diameter, 1" (25mm) throw.
• Strike: 1-1/8" x 2-3/4" (29mm x 70mm) round corner faceplate.
• Cylinder: 5-Pin, Schlage "C" keyway (SC1), keyed different (KD).
• Pin & tumbler (standard)
• Keying Options: See "keying" for the following keying options on the B60/B62 Deadbolt:
• Keyed Alike: 1 key works all locks.
• Master Keyed: Locks are keyed different (KD) with 2 keys per lock, 1 master key opens all locks.
• Construction Key: PK.

Functions:

• Single Cylinder Latch: Key operates deadbolt from outside; turn piece operates deadbolt.
• Double Cylinder Latch: Deadbolt operated by key from either side; no turn knob.

Finishes:

• 605 - Bright brass
• 608 - Satin brass
• 609 - Antique brass
• 618 - Polished nickel
• 619 - Satin nickel
• 620 - Antique pewter
• 621 - Distressed nickel
• 622 - Batte black
• 625 - Bright chrome
• 626 - Satin chrome
• 716 - Aged bronze

Features

• Keying Options: See "keying" for the following keying options on the B60/B62 Deadbolt:
• Cylinder: 5-Pin, Schlage "C" keyway (SC1), keyed different (KD).
• Pin & tumbler (standard)
• Strike: 1-1/8" x 2-3/4" (29mm x 70mm) round corner faceplate.
• Master Keyed: Locks are keyed different (KD) with 2 keys per lock, 1 master key opens all locks.
• Door Range: 1-3/8" - 1-3/4" (35mm - 44mm).
• Latch: 1" x 2-1/4" (25mm x 57mm) Round Corner, 1" (25mm) housing diameter, 1" (25mm) throw.
• Keyed Alike: 1 key works all locks.
• Construction Key: PK.
• Backset: Dual backset latch; adjustable for 2-3/8" or 2-3/4" backset.
• Door Prep: Required 1" door prep for larger bolt housing.
