Manufacturer surcharge: 3.5%
Accessible: Yes
Ada Compliance: Yes
Ansi: ANSI A156.36-2010 Grade 1
Ansi Function: E0151 - Single Cylinder Deadbolt
Application: Extended Equally
Baa Qualified: Yes
Backset: Adjustable Backset
Base Material: Brass or Bronze
Bolt Projection: 1"
Bolt Throw: 1"
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Conventional Cylinder
Door Thickness: 2-1/2"
Dust Box: Metal
Finish: Satin Chrome
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Function: 660-Single Cylinder Deadbolt
Function Family: Entrance/Office
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Keying: Keyed Different
Keys: 2
Latch Backset Dim: 2-3/8" or 2-3/4"
Limited Warranty: 3 Years
Lock Face Size: 2-1/4" x 1-1/8"
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Product Height: 4.13"
Product Width: 2.54"
Screws: Combination
Series: B600 Series
Std Latch Backset Dim: 2-3/8" or 2-3/4"
Std Latch Number: 12-296
Std Latch Type: Square Corner
Std Strike Height: 2-3/4"
Std Strike Number: 10-094
Std Strike Type: Flat Square Corner
Std Strike Width: 1-1/8"
Strike: Square 2-3/4" Strike
Subtype: Deadbolts
Type: Mechanical Commercial Locksets
Ul Listing: UL10B/10C Listed
Unit of Measure: Each
