Attributes
Ship via: Can Ship UPS
Manufacturer surcharge: 4.5%
Ansi: ANSI A156.36-2010 Grade 1
Ansi Function: E0141 - Double Cylinder Deadbolt
Baa Qualified: Yes
Backset: Adjustable Backset
Base Material: Brass or Bronze
Bolt Projection: 1"
Bolt Protection: 1 In.
Bolt Throw: 1"
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Conventional Cylinder
Door Thickness: 1-5/8 In. - 2 In.
Dust Box: None
Finish: 625/US26
Finish Description: Bright Chrome
Finish Family: Polished Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Function: 662-Double Cylinder Deadbolt Lock
Function Family: Institution
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Keying: Keyed Different
Keys: 2
Keyway: S123
Latch Backset Dim: 2-3/4 In.
Latch Number: 12-631
Latch Type: Deadbolt
Limited Warranty: 3 Years
Lock Face Size: 2-1/4 In. x 1-1/8 In.
Num Pins: 6
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Product Height: 4.13"
Product Width: 2.54"
Screws: Combination
Series: B600 Series Deadbolt
Std Latch Backset Dim: 2-3/8" or 2-3/4"
Std Latch Number: 12-296
Std Latch Type: Square Corner
Std Strike Height: 2-3/4"
Std Strike Number: 10-094
Std Strike Type: Flat Square Corner
Std Strike Width: 1-1/8"
Strike: Square 2-3/4" Strike
Strike Height: 2-3/4 In.
Strike Number: 10-094
Strike Type: Flat
Strike Width: 1-1/8 In.
Subtype: Deadlock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL10B/10C Listed
Unit of Measure: Each
