Latchbolt retracted by knob/lever from either side unless outside is locked by inside thumbturn.Turning inside knob/lever or closing door unlocks outside knob/lever. To unlock from outside, remove emergency button, insert emergency thumbturn(furnished).
Attributes
Alternate Codes: L9040-17A-626 L583-363, L904017A626 L583-363, L904017A626L583363, SCHL904017A626 L583-363
Ansi: A156.13-2017 Series 1000, Grade 1
Ansi Function: F22 - Privacy
Baa Qualified: Yes
Backset: 2-3/4"
Bolt Projection: 3/4" Latch
Category: Lock Sets, Mortise Locks, Mortise Lock Sets
Commercial Residential: Commercial
Country of Origin: Mexico
Country of origin: Mexico
Door Application: Mortise Electric, Mortise Lock Body, Mortise Lock Sets
Door Thickness: 1-3/4"
Finish: 626/US26D
Finish Code: 626
Finish Color: Brushed Chrome, Satin Chrome
Finish Description: Satin Chrome
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: Privacy
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Latch Bore Diameter: 2-3/4"
Lever Design: 17
Leverknob Design: 17 Lever
Leverknob Design Family: Curved Return Lever
Limited Warranty: 3 Years
Lock Category: Mortise Lockset - Latch Only
Lock Face Size: 8" x 1-1/4"
Origin: Mexico
Pack Height: 5.5"
Pack Length: 10.25"
Pack Qty: 1
Pack Volume: 295.97 in³
Pack Width: 5.25"
Projection: 3"
Rose/ Escutcheon: A Rose
Roseescutcheon Design: A Rose
Roseescutcheon Dimensions: 2-1/8"
Series: L Series
Ship Weight: 6 lbs.
Std Latch Backset Dim: 2-3/4"
Std Latch Type: Spring Latch (Unguarded)
Std Strike Height: 4-7/8"
Std Strike Number: 10-072 1316 626
Std Strike Type: ANSI Strike
Std Strike Width: 1-3/16"
Subtype: Mortise Lock
Thumbturn Style: Large ADA Thumbturn
Type: LOCK SETS
Ul Listing: UL Listed
Unit of Measure: Each
