Schlage JD60619 Satin Nickel Single Cylinder Deadbolt with C Keyway and Latch 16068
Images may not represent actual product and finish

Schlage JD60619 Satin Nickel Single Cylinder Deadbolt with C Keyway and Latch 16068

Your Price: $30.43
Retail Price:$52.00
Your Savings:$21.57(41%)
Schlage JD60619 Single Cylinder Deadbolt offers durable security with satin nickel finish, easy installation, and lifetime warranty.
Part Number : SCH_JD60619
Availability: 7615 In Stock
Schlage JD60619 Satin Nickel Single Cylinder Deadbolt with C Keyway and Latch 16068

Schlage Residential - J Series JD60619 Single Cylinder Deadbolt with C Keyway offers a perfect blend of security and style for any home. Constructed from durable zinc material and finished in sleek satin nickel, this deadbolt is designed to withstand the test of time while enhancing the aesthetic appeal of your doors. With an ANSI/BHMA A156.36 Grade 3 rating, it provides reliable protection you can count on. This single cylinder deadbolt can be easily unlocked using a key from the outside or a thumbturn from the inside, ensuring convenience and accessibility. The reversible handing allows for flexible installation, accommodating doors ranging from 1-3/8" to 1-3/4" in thickness. The adjustable backset of 2-3/8" or 2-3/4" further simplifies the installation process, which includes all necessary mounting hardware. With a limited lifetime mechanical warranty and a 5-year finish warranty, the Schlage JD60619 is backed by a trusted name in lock security. Its 5-pin Schlage C keyway enables compatibility with other Schlage locks for key convenience. Whether you're a building professional or a knowledgeable homeowner, this deadbolt provides peace of mind without compromising on style or functionality.

Single Cylinder Deadbolt with C Keyway 16068 Latch and 10267 Strike Satin Nickel Finish

Perfect for any home, with a 25-year mechanical warranty, Dexter products are built to last. Dexter by Schlage J Series Products are backed by a lifetime mechanical warranty and 5 year finish and made by a name you can trust. These durable grade 3 products are easy to install and fit standard door preps. Focused on elegant, sleek designs and the ability to be keyed to other Schlage locks for one key-convenience, customers know they are getting the best in affordable lock security. Dexter also focuses on the ease of installation, with products that often have a one-tool installation to make the process as seamless as possible. Though the installation is easy, Dexter products are dependable in their security.


  • Easy installation
  • Fits all standard door preparations
  • Lifetime mechanical warranty and 5-year finish warranty
  • Deadbolt thrown or retracted by key from outside or by inside turn unit
  • Can be rekeyed to match existing locks or other locks purchased
  • Includes All Mounting Hardware for Easy Installation
  • Reversible Handing
  • ANSI/BHMA A156.36 Grade 3
  • Lifetime Mechanical & 5 Year Finish Warranty
  • Single Cylinder Deadbolt - Unlocked by Key from Outside or by Inside Thumbturn
  • Easy Install: Requires a screwdriver and fits all standard doors; designed to fit 1-3/8 inch to 1-3/4 inch-thick doors; adjustable latch fits 2-3/8 inch and 2-3/4 inch backset; package includes all needed mounting hardware
  • Security: A 1 -inch deadbolt with a hardened steel core, paired with a keyed entry knob to protect against forced entry; drill-resistant metal deadbolt cylinder housing; keyable to other Schlage locks (SC1)
  • Dependable Design: Certified CCC by ANSI/BHMA in Security, Durability and Finish; strong, metal construction for long-lasting durability; finished latch bolt to protect against corrosion; extended screw posts for added stability
  • Certified: Commercial Grade 3
  • Quality Warranty: Backed by a limited lifetime mechanical warranty and a limited five year finish warranty; see full warranty for details
  • Ideal Use: Best for residential doors that require keyed access to enter and the strength of a deadbolt to secure; includes two keys
  • Function: Deadbolt locks/unlocks from the outside with a key and locks/unlocks with a thumbturn from the inside

Attributes

Alternate Codes: 043156892327, 135315, DEXJD60619, JD60619

Backset: Adjustable 2-3/8" or 2-3/4" Backset

Category: Mechanical Residential Locksets

Crossbore Size: 2-1/8" Bore

Cylinder Included: Yes

Cylinder Type: 5 Pin Cylinder

Dimension: 2-5/8" Diameter and 1" Projection

Door Bore Size: 2-1/8"

Door Range: 1-3/8" to 1-3/4"

Door Thickness: 1-3/8" to 1-3/4"

Door Thickness Max: 1-3/4"

Door Thickness Min: 1-3/8"

Finish: Satin Nickel

Finish Code: 619

Finish Color: Satin Nickel

Function: Single Cylinder

Grade: Grade 3

Handing: Reversible

Hazardous Material: NO

Keyway: Schlage C Keyway

Knob/ Lever Style: Inside Thumbturn

Latch Bolt Face Type: Drive-In, Round Corner, Square Corner

Latch Bolt Faceplate Size: 2-1/4" x 1"

Latch Bolt Throw: 1"

Latch Bolt Type: Deadbolt

Latch Faceplate Dimension: Round Corner 1" x 2-1/4" Faceplate or 1" Collar

Lock Category: Deadbolt

Manufacturer Warranty: Limited Lifetime Mechanical and 5 Year Finish Warranty

Material: Zinc

No Of Inners: 1

No Of Pins: 5 Pin Cylinder

Order_ Qty: 1

PO date: 2024-09-03

Restricted Keyway: No

Series: J Series

Strike: Radius Deadbolt Strike

Strike Dimension: 1-1/8" x 2-3/4"

Strike Size: 2-1/4" x 1"

Subcategory: Residential Deadbolts

Supplier: Schlage

Type: LOCK SETS
