Schlage Commercial ND53BDSPA622 ND Series Entry Small Format Less Core Sparta with 13-247 Latch 10-025 Strike Matte Black Finish
Attributes
Ship via: Can Ship UPS
Manufacturer surcharge: 2.0%
Accessible: Yes
Ada Compliance: Yes
Alternate Codes: ND53BDSPA622
Ansi: ANSI A156.2 Series 4000, Grade 1
Ansi Function: F109 - Entry/Office
Baa Qualified: Yes
Backset: 2-3/4" Backset
Bolt Projection: 1/2 In.
Bore Hole Diameter: 2-1/8 In.
Box Depth Fraction: 9-1/2 In.
Box Height Fraction: 4-3/4 In.
Box Width Fraction: 8-1/4 In.
Category: Commercial Locks, Cylindrical Levers, Lock Sets
Commercial Residential: Commercial
Country of Origin: Mexico
Country of origin: Mexico
Cylinder Type: Less Core, SFIC
Cylinders Present: Single Cylinder
Design: Sparta
Door Application: Cylindrical Levers
Door Thickness: 1-5/8 In. to 2-1/8 In.
Finish: Matte Black
Finish Code: 622
Finish Color: Black, Flat Black, Flat Black Coated, Matte Black
Finish Description: Matte Black
Finish Family: Black
Fire Rated: Yes
Fire Rating: 180 min
Function: Entry
Function Family: Entrance
Grade: Grade 1
Handing: Non-handed
Installation: Commercial
Latch Bore Diameter: 1 In.
Lever Design: Sparta
Lever Knob: Lever
Lever Knob Design Name: Sparta
Leverknob Design: SPA - Sparta Lever
Leverknob Design Family: Curved Return Lever
Limited Warranty: 10 Years
Lock Face Size: 1-1/8 In. x 2-1/4 In.
Manufacturer Function: Entrance Lock
Maximum Door Thickness: 2-1/8 In.
Minimum Door Thickness: 1-5/8 In.
Origin: Mexico
Pack Height: 4.75"
Pack Height 2: 10"
Pack Length: 9.5"
Pack Length 2: 16.38"
Pack Qty: 1
Pack Volume: 372.28 in³
Pack Volume 2: 2394.84 in³
Pack Width: 8.25"
Pack Width 2: 14.63"
Pbs Options: '4540301,4541421
Product Height: 3.44"
Product Length: 6.66"
Product Width: 3.5"
Projection: 3-1/2 In.
Rose Escutcheon: Rose
Roseescutcheon Design: 3-7/16" Rose Diameter
Roseescutcheon Dimensions: 3-7/16"
Screws: Wood/Machine Screws
Series: ND
Ship Weight: 5 lbs.
Std Latch Backset Dim: 2-3/4 In.
Std Latch Number: 13-247
Std Latch Type: Deadlatch
Std Strike Height: 4-7/8 In.
Std Strike Number: 10-025
Std Strike Type: ANSI Strike
Std Strike Width: 1-1/4 In.
Strike: ASA Strike
Strike Dimensions: 1-1/4 In. x 4-7/8 In.
Subtype: Cylindrical
Type: Mechanical Commercial Locksets
Ul Listing: UL/cUL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
