Attributes

Ship via: Can Ship UPS

Ansi Function: F86 - Storeroom

Ansi Function Description: Storeroom

Baa Qualified: Yes

Backset: Adjustable Backset

Bolt Protection: 1/2 In.

Bore Hole Diameter: 2-1/8"

Country of Origin: Mexico

Cylinder Type: Conventional Cylinder

Cylinders Present: Single Cylinder

Design: Neptune

Door Thickness: 1-3/4 In.

Dust Box: Plastic

Finish: 613/US10B

Finish Description: Dark Oxidized Satin Bronze Oil Rubbed

Fire Rated: 3 Hours {A}

Function: 80-Storeroom Lock

Function Family: Storeroom

Grade: Grade 2

Hand: Non-handed

Keys: Cut

Keyway: S123

Latch Backset Dim: Adjustable 2-3/8 In. and 2-3/4 In.

Latch Bore Diameter: 7/8"

Latch Number: 16-203

Latch Type: Dead Latch (Guarded)

Lever Knob: Lever

Lever Knob Design: NEP - Neptune

Lever Knob Design Family: Curved Lever

Lever Knob Design Name: Neptune

Limited Warranty: 3 Year Warranty

Lock Face Size: 2-1/4 In. x 1 In.

Manufacturer Function: Storeroom Lock

Manufacturer Function Description: Outside knob fixed. Entrance by key only. Inside knob always unlocked.

Maximum Door Thickness: 2"

Minimum Door Thickness: 1-3/8"

Num Of Keys: 2

Num Pins: 6

Projection: 2-1/2"

Restrictions: None

Rose Escutcheon: Rose

Rose Escutcheon Design: 2-1/2" Rose Diameter

Rose Escutcheon Dimensions: 2-1/2"

Screws: Wood/Metal Screws

Series: S Series Tubular Lever Locks

Strike: T Strike

Strike Dimensions: 1-1/8" x 2-3/4"

Strike Height: 2-3/4 In.

Strike Number: 10-001

Strike Type: T-Square Corner

Strike Width: 1-1/8 In.

Structure Cylinder: P

Structure Function: 80

Structure Latch: D

Structure Latch Number: 16-203

Structure Outside Finish: 613

Structure Outside Trim: NEP

Structure Series: S

Structure Strike Number: 10-001

Subtype: Tubular Lock

Type: Locks, Cylinders, Cores, Keyblanks

Upc: 043156942114
