Manufacturer surcharge: $ 0.0
Ansi: 294
Baa Qualified: Yes
Base Material: Stainless Steel
Burglar Rated: No
Commercial Residential: Commercial
Country of Origin: Usa
Country of origin: USA
Current 12v DC (m A): 300
Current 24v DC (m A): 150
Door Type: Inswing Door|Single Door|Double Door
Finish: Satin Stainless Steel
Finish Description: Satin Stainless Steel
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Fire Rating (hrs): 3
Frame Material: Wood|Metal|Aluminum Glass
Grade: Grade 3
Holding Force (lbs): 600
Installation: Commercial
Limited Warranty: Lifetime
Magnet Depth (in): 1.625
Magnet Height (in): 1.875
Magnet Length (in): 8
Maximum Operating Temperature (° F): 140
Minimum Operating Temperature (° F): -40
Monitoring Options: BondSTAT Monitor & Door Position Switch
Mounting: Face Drilled
Operating Voltage: 12VDC/24VDC
Options: Standard Strike
Origin: USA
Outdoor Rated: Yes
Pack Qty: 1
Preload Capable: Yes
Product Height: 1.63"
Product Length: 8"
Product Width: 1.88"
Restrictions: None
Series: M32 Series
Ship Weight: 6 lbs.
Subtype: Magnetic Locks
Switch Type: MBS/DPS
Type: Electronics
Ul Listing: 10C
Unit of Measure: Each
Upc: 784607036449
Voltage: 12/24
