Manufacturer surcharge: $ 0.0
Alternate Codes: M82BD
Ansi: 294, A156.23, E08501-1000
Baa Qualified: Yes
Base Material: Stainless Steel
Burglar Rated: No
Category: Access Control, Maglocks, Single Maglocks
Commercial Residential: Commercial
Country of Origin: Usa
Country of origin: USA
Current 12v DC (m A): 350
Current 24v DC (m A): 200
Finish: Satin Stainless Steel
Finish Description: Satin Stainless Steel
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Grade: Grade 1
Holding Force (lbs): 1800
Installation: Commercial
Limited Warranty: Lifetime
Magnet Depth (in): 2.25
Magnet Height (in): 3
Magnet Length (in): 12
Maximum Operating Temperature (° F): 140
Minimum Operating Temperature (° F): -40
Monitoring Options: BondSTAT Monitor & Door Position Switch
Mounting: Direct Mount
Operating Voltage: 12VDC/24VDC
Options: Standard Strike
Origin: USA
Outdoor Rated: Yes
Pack Qty: 1
Preload Capable: Yes
Product Height: 3"
Product Length: 12"
Product Width: 1.75"
Restrictions: None
Series: M82 Series
Ship Weight: 16 lbs.
Subtype: Magnetic Locks
Switch Type: MBS/DPS
Type: Electronics
Ul Listing: 10C, 294
Unit of Measure: Each
Upc: 784607036531
Voltage: 12/24
