Manufacturer surcharge: $ 0.0
Alt Part No: 257052
Ansi: 294, A156.23, E08561-1000, E08571-1000, E08581-1000, E08591-1000
Baa Qualified: Yes
Base Material: Stainless Steel
Burglar Rated: No
Category: Maglocks
Commercial Residential: Commercial
Country of Origin: Usa
Country of origin: USA
Current 12v DC (amps): 320
Current 24v DC (amps): 170
Finish: Satin Stainless Steel
Finish Description: Satin Stainless Steel
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Grade: Grade 2
Holding Force (lbs): 1200
Installation: Commercial
Length: 0.0
Limited Warranty: Lifetime
Magnet Depth (in): 1.188
Magnet Height (in): 1.5
Magnet Length (in): 10.875
Maximum Operating Temperature (° F): 140
Minimum Operating Temperature (° F): -40
Monitoring Options: BondSTAT Monitor|Door Position Switch
Operating Voltage: 12VDC/24VDC
Origin: USA
Outdoor Rated: No
Pack Qty: 1
Preload Capable: Yes
Product Height: 1.19"
Product Length: 10.88"
Product Width: 1.5"
Restrictions: None
Sales Unit: EA
Series: Securitron Specialty Magnalocks
Ship Weight: 6 lbs.
Subtype: Magnetic Locks
Type: Electronics
Ul Listing: 10C, 294,
Unit of Measure: Each
Upc: 784607036609
Voltage: 12/24
