Select Hinges SL24 CL HD600 83 ATW4 RH Continuous Full Mortise Hinge

Select Hinges SL24 CL HD600 83 ATW4 RH Full Mortise Continuous Hinge delivers exceptional performance and durability for commercial applications. This Grade 1 electrified geared continuous hinge is designed to support heavy-duty doors weighing up to 600 lbs, ensuring smooth operation and longevity. With a concealed leaf design and a standard height of 83 inches, this hinge seamlessly integrates into your door system for a clean aesthetic. The hinge features an accessible through-wire prep with 4-22GA power transfer and Molex connectors, making it an ideal choice for applications requiring electrical access. Its clear anodized aluminum finish not only enhances its visual appeal but also provides resistance against wear and tear. The patented 3-hour fire rating, certified for both positive and negative pressure, guarantees safety without the need for pins or studs. Select Hinges offers additional customization options, including various lengths and finishes, to meet specific project requirements. This continuous hinge is UL Listed, ensuring compliance with industry standards. Backed by a lifetime limited warranty, the SL24 CL HD600 provides peace of mind while enhancing the functionality and security of your commercial spaces.

Full Mortise Continuous Hinge

Grade 1 Electrified Geared Continuous Hinge, Concealed Leaf, 83", Heavy Duty, Up to 600 lbs., Accessible Through-Wire Prep, 4-22GA, Molex Connectors, Clear Anodized Aluminum Finish, Right-Handed

SELECT hinges outperform most entrance components because they distribute door weight along the full length of the door frame. They offer a patented 3-HR. Fire Rating without pins or studs and are approved for both positive and negative pressure. They come in standard 83", 85", 95" and 120" hinge lengths, anodized Clear or Dark Bronze and offer a variety of custom lengths, custom anodizing, custom painted finishes and custom electric preparations.
