Von Duprin CD98L-NL-06 3 315 RHR Grade 1 Rim Exit Device offers robust security and reliable performance for commercial spaces. Designed for both single and double doors, this Grade 1 exit device is UL listed for panic exit hardware, making it an ideal choice for schools, hospitals, and government buildings. With a length of 36 inches, the device features a night latch and cylinder dogging, ensuring ease of use while maintaining safety standards. The sleek black anodized aluminum finish not only enhances aesthetic appeal but also provides durability. Engineered with a deadlocking latch bolt that has a 3/4" throw, this device ensures secure closure, while the wide stile pushpad design allows for easy operation, even in high-traffic environments. The adjustable device functions can be tailored to meet specific access control needs by simply changing the drive screw. Installation is straightforward, accommodating door thicknesses from 1-3/4" to 2-1/4" and widths of 28" to 36". With a centerline height from the finished floor of 39 13/16", it meets ergonomic standards for accessibility. Backed by a 3-year limited warranty, the Von Duprin CD98L-NL-06 is a reliable choice for those seeking high-performance exit solutions.
Grade 1 Rim Exit Device 711
Grade 1 Rim Exit Device, 36", Night Latch, Cylinder Dogging, 06 Lever, 1-1/4" Mortise & Rim, Black Anodized Aluminum Finish, Right-Hand Reverse
98 and 99 Rim exit devices for all types of single and double doors with mullion, UL listed for panic exit hardware. Devices are ANSI A156.3 _ 2008 Grade 1
Heavy-duty high-performance exit devices with many customizable options.
Von Duprin's 98 Series Exit Devices are wide stile, heavy-duty push pads. They are certified to the maximum industry standards and ideal for use in schools, hospitals and government buildings.
Specifications:
Manufacturer surcharge: 3.5%
Accessible: No
Ada Compliance: No
Ansi: A156.3 2014
Baa Qualified: Yes
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: 1-1/4" Mortise & Rim
Device Length: 36"
Device Type: Rim
Dogging Options: Cylinder Dogging
Door Material: Wood or Metal
Door Thickness: 1-3/4" to 2-1/4"
Door Width: 28" to 36"
Finish: 315/335
Finish Family: Black
Fire Rated: No
Fire Rating: No
Grade: Grade 1
Handing: Right-Hand Reverse
Includes Cylinders: No
Includes Trim: Yes
Installation: Commercial
Limited Warranty: 3 Years
Mechanical Function: Night Latch
Minimum Stile Size: 4-1/2"
Origin: USA
Pack Height: 10.5"
Pack Height 2: 11.75"
Pack Length: 37"
Pack Length 2: 41"
Pack Qty: 1
Pack Volume: 1942.5 in³
Pack Volume 2: 7708 in³
Pack Width: 5"
Pack Width 2: 16"
Physical Appearance: Wide Stile Pushpad
Product Height: 8"
Product Length: 33"
Product Width: 3.75"
Reversible: Yes
Series: 98 Series Rim Exit Device
Ship Weight: 19 lbs.
Strike Standard: 299
Subtype: Rim Exit Devices
Trim Design: Lever with Escutcheon
Trim Part No: 996L-NL-06-R/V US19 RHR
Trim Type: Lever
Type: Exit Devices
Ul Listing: UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 3
