Yale 720 XF 605-ISO Oxford Interior Trim Knob, Single Cylinder Deadbolt, Polished Brass, Grade 2

Yale Residential 720 XF 605-ISO Interior Trim Knob combines elegance with robust security, featuring the Oxford knob design and a single cylinder deadbolt for added peace of mind. Crafted as part of the YH collection, this lock embodies Yale's commitment to quality and craftsmanship that dates back to the mid-19th century. This Grade 2 lockset is designed for light commercial use, ensuring durability and reliability. The adjustable backset accommodates both 2-3/8" and 2-3/4" settings, making installation a breeze with the easy-mount square spindle system and pre-installed screws. The polished brass finish adds a touch of sophistication to any interior door while concealed mounting screws create a clean, modern look. Functionality is paramount, featuring a push-button locking mechanism for panic-free egress. The heavy-duty shroud enhances security against prying, while the four-wound spring chassis ensures a solid feel and eliminates lever sag. Door compatibility ranges from 1-3/8" to 1-3/4" in thickness, with a 2-1/8" face bore for a precise fit. With a lifetime limited warranty on the finish and mechanical parts, the Yale Residential 720 XF 605-ISO is an exceptional choice for those seeking a blend of style, functionality, and security in their home.

Interior Trim Knob - Oxford, Single Cylinder Deadbolt, RC Adjustable Backset 2-3/8in - 2-3/4in, Grade 2, Polished Brass 605/US3

The YH collection from Yale continues a legacy of distinctive design, high manufacturing standards and demanding performance started by Linus Yale in the mid-19th century. The YH collection leverages years of engineering refinement with artful execution to offer a series of ANSI/BHMA grade 2 superior light commercial quality locks that will beautifully serve facilities for generations. They offer superior functionality such as push-button locking, removable trim for simple re-keying, and a lifetime limited finish and mechanical warranty.

Features:

• Available in 9 distinctive finishes
• Easy install mounting system – square spindle simplifies installation - knobs, levers
• Pre-installed mounting screws
• Concealed mounting screws – clean upgraded look
• Available KW-1, SC-1 keyway
• E1R (Para) keyway available for deadbolts and levers only
• Push button locking – panic-free egress
• Solid brass key cylinder and housing
• Removable lever/knob and rosettes – allows for easy scratch-free installation
• Front removable deadbolt cylinder – premier series
• Heavy-duty shroud – added anti-pry security
• Four-wound spring chassis – heavy-duty feel, eliminates lever sag
• Warranty - 3-year mechanical and 1-year finish when used in commercial, institutional or industrial applications

Specifications:

• Door Specs:
• 2-1/8" Face bore
• 1" Edge bore
• 2-3/8" Backset
• Latch: 2-3/8" RC (round corner)
• Door Thickness: 1-3/8" to 1-3/4"
• Cylinder: 6-Pin cylinder, KW-1 compatible
• Keying: KA3 (keyed alike)
• Faceplate: 1" W x 2-1/4" H, RC (round corner)
• Strike: 2-1/4" Full Lip, RC (round corner)
• Fire Listing: Optional UL-cUL fire listing with 1/2" latchbolt for use with doors rated 90 minutes or less measuring up to 4' in width and 8' in height.
• Certified: A156.2 Series 4000, grade 2

Knob Selection:

• BP: Bridgeport
• DM: Dartmouth
• CB: Cambridge
• XF: Oxford

Knob Functions:

• 80: Dummy
• 10: Passage
• 60: One sided w/plate
• 20: Privacy
• 26: Bath: Privacy with US26 interior finish
• 70: Entry
• 75: Classroom
• 78: Storeroom

Finishes:

• 605/US3 - Bright brass
• 609/US5 - Satin brass, blackened, satin relieved, clear coated
• 613e/US10BE - Dark oxidized satin bronze, permanent
• 619/US15 - Satin nickel plated, clear coated
• 620/US15A - Satin nickel plated, blackened, satin relieved, clear coated
• 625/US26 - Bright chrome plated
• 626/US26D - Satin chrome plated
