Yale 720 XF 619-ISO Oxford Interior Trim Knob, Single Cylinder Deadbolt, Satin Nickel, Grade 2

Yale Residential 720 XF 619-ISO Interior Trim Knob - Oxford combines elegant design with robust functionality, making it an ideal choice for any residential space. This single cylinder deadbolt features an adjustable backset of 2-3/8 inches to 2-3/4 inches, ensuring a perfect fit for various door types. With a Grade 2 rating, it exemplifies superior light commercial quality, backed by the legacy of Linus Yale. Crafted with a satin nickel finish, the 720 XF is not only aesthetically pleasing but also built to last, with a lifetime limited finish and mechanical warranty. The easy-install mounting system, featuring pre-installed screws and concealed mounting, simplifies the installation process while providing a clean, upgraded look. Push-button locking allows for panic-free egress, while the solid brass key cylinder enhances security. This knob is designed for doors with a thickness ranging from 1-3/8 inches to 1-3/4 inches and includes a heavy-duty shroud for added anti-pry security. The four-wound spring chassis provides a robust feel and eliminates lever sag. The Yale Residential 720 XF is available in various finishes, allowing you to select the perfect match for your decor. Upgrade your home’s security and style with this exceptional interior trim knob.

Interior Trim Knob - Oxford, Single Cylinder Deadbolt, RC Adjustable Backset 2-3/8in - 2-3/4in, Grade 2, Satin Nickel 619

The YH collection from Yale continues a legacy of distinctive design, high manufacturing standards and demanding performance started by Linus Yale in the mid-19th century. The YH collection leverages years of engineering refinement with artful execution to offer a series of ANSI/BHMA grade 2 superior light commercial quality locks that will beautifully serve facilities for generations. They offer superior functionality such as push-button locking, removable trim for simple re-keying, and a lifetime limited finish and mechanical warranty.

Features:

• Available in 9 distinctive finishes
• Easy install mounting system – square spindle simplifies installation - knobs, levers
• Pre-installed mounting screws
• Concealed mounting screws – clean upgraded look
• Available KW-1, SC-1 keyway
• E1R (Para) keyway available for deadbolts and levers only
• Push button locking – panic-free egress
• Solid brass key cylinder and housing
• Removable lever/knob and rosettes – allows for easy scratch-free installation
• Front removable deadbolt cylinder – premier series
• Heavy-duty shroud – added anti-pry security
• Four-wound spring chassis – heavy-duty feel, eliminates lever sag
• Warranty - 3-year mechanical and 1-year finish when used in commercial, institutional or industrial applications

Specifications:

• Door Specs:
• 2-1/8" Face bore
• 1" Edge bore
• 2-3/8" Backset
• Latch: 2-3/8" RC (round corner)
• Door Thickness: 1-3/8" to 1-3/4"
• Cylinder: 6-Pin cylinder, KW-1 compatible
• Keying: KA3 (keyed alike)
• Faceplate: 1" W x 2-1/4" H, RC (round corner)
• Strike: 2-1/4" Full Lip, RC (round corner)
• Fire Listing: Optional UL-cUL fire listing with 1/2" latchbolt for use with doors rated 90 minutes or less measuring up to 4' in width and 8' in height.
• Certified: A156.2 Series 4000, grade 2

Knob Selection:

• BP: Bridgeport
• DM: Dartmouth
• CB: Cambridge
• XF: Oxford

Knob Functions:

• 80: Dummy
• 10: Passage
• 60: One sided w/plate
• 20: Privacy
• 26: Bath: Privacy with US26 interior finish
• 70: Entry
• 75: Classroom
• 78: Storeroom

Finishes:

• 605/US3 - Bright brass
• 609/US5 - Satin brass, blackened, satin relieved, clear coated
• 613e/US10BE - Dark oxidized satin bronze, permanent
• 619/US15 - Satin nickel plated, clear coated
• 620/US15A - Satin nickel plated, blackened, satin relieved, clear coated
• 625/US26 - Bright chrome plated
• 626/US26D - Satin chrome plated
